Summary of Contents for Chauvet Pro-D6
-
Page 1: User Manual
Snapshot Pro-D6™ OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Circuit Breaker User Serviceable Duty Cycle USER MANUAL 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
To set maximum output value in dmx mode: ...11 To manually set dimming:...11 ...12 ENERAL ROUBLESHOOTING ...13 ECHNICAL UPPORT 5. APPENDIX...13 DMX P ...13 RIMER ...14 ENERAL AINTENANCE ...14 ETURNS ROCEDURE ...14 LAIMS ...15 ECHNICAL PECIFICATIONS Pro-D6 User Manual ... 8 2/18/2008 12:58 PM... -
Page 3: Before You Begin
1. B EFORE What is included 1 x Pro-D6™ Warranty Card User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 4: Safety Instructions
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Pro-D6 User Manual 2/18/2008 12:58 PM... -
Page 5: Introduction
• Each channel can be set to any DMX address ADDITIONAL FEATURES • Dual 20A power lines (requires 2 separate circuits) • Individual switch, circuit breaker and plug per line • Accommodates different voltages per line (simultaneously) Pro-D6 User Manual 2/18/2008 12:58 PM... -
Page 6: Product Overview
Product Overview Line A (Channel 1-3) Line A Circuit Breaker DMX In Line A Power Switch Line A Power Cord Pro-D6 User Manual Line B (Channels 4-6) Line B Circuit Breaker DMX Out Line B Power Switch Line B Power Cord... -
Page 7: Setup
Nominal impedance 100 – 140 ohms POW ER CONN EC TION The Pro-D6 has been designed to work on multiple input voltages (115V and 230V) simultaneously, and comes fitted with 20 amp connectors for this purpose. For example, Line A can be plugged into 115V and Line B can be plugged into 230V. -
Page 8: Cable Connectors
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. Note! Note! CHAUVET Model No: DMX5M, or DMX5F. CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion:... -
Page 9: Mounting
To return to the previous option or menu without changing the value, press the <MENU> button. Note: Line A must be used when only one line is needed in order for the unit to function properly. Pro-D6 User Manual NSTRUCTIONS Function... -
Page 10: Menu Map
Menu Map Pro-D6 User Manual 2/18/2008 12:58 PM... -
Page 11: Menu Functions
The display will stop flashing at this point. If you would like to set another channel, pressing enter again will allow access to set the manual value for channel 2. Each channel becomes available once the channel immediately preceding it is set. Pro-D6 User Manual 2/18/2008 12:58 PM... -
Page 12: General Troubleshooting
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. Pro-D6 User Manual... -
Page 13: Technical Support
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) -
Page 14: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 15: Technical Specifications
Data output ... locking 3-pin XLR female socket Data pin configuration ...pin 1 shield, pin 2 (-), pin 3 (+) Protocols... DMX-512 USITT ORDERING INFORMATION Pro-D6 ... Pro-D6 WARRANTY INFORMATION Warranty ... 2-year limited warranty Pro-D6 User Manual 2/18/2008 12:58 PM...
