LEAKSHIELD
On the Status page, all current operating data of LEAKSHIELD are visualized. For
this purpose, the status, the current negative pressure, the volume change in ml/h
and the pressure change in mbar per minute are displayed as values in the upper
area.
By clicking on one of the radio buttons, the corresponding value can be displayed
in a diagram below in the change over time.
The size of the diagram can be changed by using the dividing line below the dia-
gram.
In the middle of the page a symbolic illustration of LEAKSHIELD is shown. This
shows the components of the system, such as the vacuum pump, valves, etc., rep-
resented by symbols.
Currently active components are displayed in green. All important measured val-
ues are shown in the schematic.
In the lower part of the page, the current events are displayed in a list together
with the time and further details. In case of malfunctions, this list can be exported
and sent to Aqua Computer for further analysis.

17. Profiles

17. Profiles
17. 17. Profiles Profiles
Select "Profiles" from the device list below the "LEAKSHIELD" entry.
The profile management can be used to to save four configurations as
profiles and activate them manually or automatically. Profile manage-
ment is a software feature of the aquasuite and requires a USB connection to the
LEAKSHIELD.

17.1. Manual profile selection

17.1. Manual profile selection
17.1. 17.1. Manual profile selection Manual profile selection
Select the profile to be activated by clicking the corresponding button.

17.2. Automatic profile selection

17.2. 17.2. 17.2. Automatic profile selection Automatic profile selection Automatic profile selection
Profiles can be activated automatically using the global profiles feature of the
aquasuite, see chapter 14.2. for details.
17.3. 17.3. 17.3.

17.3. Profile configuration

Profile configuration Profile configuration Profile configuration
All configuration changes are automatically stored in the currently active profile.
The current configuration can also be stored in any other profile by clicking the
corresponding button.
