Summary of Contents for EuropAce EPU 9800W

  • Page 1 9800W Instruction Manual 产品使用说明书 For safety purpose, please read this operating instruction manual carefully before using and keep it for future reference.
  • Page 2: Table Of Contents

    Content I. Performance index........01 II. Functions..........01 III. Features..........01 IV. Characteristics of filter screen....01 V. Product Structure.........02 VI. Key & Display Panel......03 VII. Requirements on the placement..05 VIII. Installation of filter screen....05 IX. Methods of Use........06 X. Maintenance and Service......09 XI.
  • Page 3: Performance Index

    Product Speci cation I. Performance Index Air purifier EPU 9800W Model Product name To eliminate the pollutants such as particulate matters (PM), gaseous pollutants, microorganisms and the like in air. PM CADR Mode of operation Intelligent purification 800m Rated voltage...
  • Page 4: Product Structure

    V. Product Structure 解 锁 锁 定 复 位 极 速 Remote controller HEPA composite HEPA composite Rear cover filter screen filter screen Front cover Primary filter screen Primary filter screen Host...
  • Page 5: Key & Display Panel

    VI. Key & Display Panel Key panel Display panel Key panel 1. Switch key and function key Power on Standby Switch key Green Function key Mode Air speed Child lock Filter screen AUTO Timing topspeed SLEEP WiFi...
  • Page 6 2.1 Replacement reminder for filter screen The machine is designed with a reminder for regular replacement of the filter screen. When the machine has been operated for 300 hours, the red indicator flashes to indicate the need of cleaning the filter screen. When the machine has been running for 3,000 hours, the red indicator on the panel will be on normally to indicate the need of replacing the filter screen.
  • Page 7: Requirements On The Placement

    VII. Requirements for the placement The back is 20cm away from the wall 30cm way from the wall 30cm way from the wall In the operation, the back of purifier should be kept 20cm away from the wall, and over 30cm on both sides. VIII.
  • Page 8: Methods Of Use

    2. Install the filter screen and the front and rear covers b.Install the primary filter screen a.Install the HEPA composite screen (with internal and external differentiation) Note: One side of the strap is installed outward Note: The side with buckle is installed outward ※...
  • Page 9 Mode selection: In the startup state, press the MODE key to select the mode: AUTO , TOPSPEED and SLEEP . When the AUTO light is on, the anion is turned on, and the gear of the motor is changed upon receiving the data of the sensor. (The icon of the key is on when the AUTO function is on, and the icon is half-lit when it is turned off).
  • Page 10 Timing: Press this key to set timing shutdown in the startup state. Touch the TIMING key, and then the timing function will be added for 1 hour every time. After pressed for 12 hours, press it again for release the timing function. The timing shall be set in the range of 1-12 hours.
  • Page 11: Maintenance And Service

    X. Maintenance and Service 1.Primary filter screen: The cleaning frequency of the primary filter screen should be determined according to the air speed, air pollution degree and cumulative operation time of product operation. It should normally be cleaned once normally for 2-3 months.
  • Page 12 4) Cleaning methods: Clean the dust and floc with vacuum cleaner or brush. If the filter screen is very dirty, it can also be cleaned with water, and then dried completely, and then installed back to the purifier. (It cannot be bent in the cleaning so as to 設定預約時間...
  • Page 13 4.Intelligent reminder for filter screen replacement: 1)Turn off the power supply and pull the power plug off the socket. 2)Open the rear cover and take down the primary filter screen according to the same method specified in “Cleaning of primary filter screen”. 3) Take out the HEPA composite filter screen to be replaced from the frame of the machine according to the replacement indication of the display panel, and then put the new filter screen into the filter screen frame in sequence, and lastly install...
  • Page 14 5. Cleaning of the machine: Cleaning of the host surface: Clean the dirt with a dry wipe, Do not wash the machine with water. Cleaning of air outlet: 1. Cut off the power and pull the plug off the power socket. 2.
  • Page 15: Precautions

    XI. Precautions Safety precautions When humidity in the room is very high, the air quality sensor may form condensed water. In this case, in the AUTO mode, even if the air quality is good, the status light on the panel will show poor air quality. It is recommended that you manually select the air volume.
  • Page 16: Xiii.troubleshooting

    XIII. Troubleshooting Common Faults Check/Solutions 1. Is the power cord plug inserted properly? The machine can't start up →Plug in the power cord plug. (the power light does not light 2. Are the left and right air inlet plates of the purifier in red) well covered? →Cover the left and right air inlet plates of the purifier.
  • Page 18 目录...
  • Page 19 EPU 9800W 1千万/cm³ AC 230V / 50Hz...
  • Page 35 The Warranty Card is not provided in the product packaging. You can register the product warranty online at our website https://www.europace.com.sg/ewarranty/ within 7 (seven) days from the date of purchase. You will enjoy an additional 3 months of the product standard warranty when you register online.
  • Page 36 - Full parts warranty apply to Refrigerators, Air Conditioners & Freezers (Outdoor warranty). Check out the warranty coverage of your appliance at www.europace.com.sg b) The owner waives all or any claims to compensation monetary or otherwise which he/she may be entitled to and shall agree to accept any compensation whatsoever by way of additional repairs or otherwise which we in our absolute discretion may deem t to o er.
  • Page 37 g) This warranty will not cover chemical cleaning, maintenance service, general service and overhaul, which if con rm is chargeable. h) Defects or fault in the appliance which has been used for commercial purposes or which have been rented/leased or which have been otherwise subject to other than household use. i) Claims for damaged/missing parts after 3 days from the original date of goods received will not be valid.
  • Page 38 RELATED PRODUCTS & MAIN CONTACT HOTLINE System Split Aircons | Tel: 6858 0801| Email: systemac@strategic.com.sg (Twin City) Portable & Casement Aircons | Tel: 6291 0800 | Email: portableac@strategic.com.sg (Jia Yue) Refrigerators, Washing machines, Cookers & other major appliances | Tel: 6289 0802 | Email: mda@strategic.com.sg (TnG)
