- Page 1 EVAPORATIVE 5 IN 1 AIR COOLER AIR PURIFIER HUMIDIFIER FAN IONIZER ECO 713Q Thank you for purchasing EuropAce Air Cooler. For safety purpose, please read this operating instruction manual carefully before using and keep it for future reference.
-
Page 2: Table Of Contents
CONTENTS Product Features…….……..……….……….……..……………3 Construction Drawing……..………...………….………………3 Accessories List………………...…..………......4 Technical Parameters………………...……......4 Operation Instruction…..……………….………………..4 Control Panel..…………………………………….…….………..5 Important Safeguards…………………………………………..6 Maintenance And Cleaning…………………………………….8 Trouble Shooting…………………..……………..……………...9... -
Page 3: Product Features
PRODUCT FEATURES 1.Cool It can lower the surrounding temperature and provide you a comfortable environment in hot weather. 2.Humidifier It gives off moisture to cool down the environment and prevent dry skin. 3.Ionizer It releases negative ions to freshen up the air and eliminate some gems and basteia in the room. -
Page 4: Accessories List
ACCESSORIES LIST Sequence Accessory Quantity(pcs) Remote Controller Instruction manual Caster wheels TECHNICAL PARAMETERS Model No. ECO 713Q Ratings 220V-240/50Hz 130W MAX Air Flow Volume Up To 1350M /H Water Tank Capacity Net Weight 11KG Product Dimensions 375X356X963MM Note: Due to constant development of our products in regards to specification and design, we take reservation for changes without prior notice. -
Page 5: Control Panel
CONTROL PANEL (Remote controller and control panel comes with the same functions) NO/OFF: Press this button once to switch ON the unit. It will start up with MID in 3 seconds and then revert to work under the memorized status. For first time usage, it will start up with MID in 3 seconds and then work with LOW. -
Page 6: Important Safeguards
LEFT/RIGHT SWING: Press this button once to activate auto left and right swing. Press this button again to cancel. UP/DOWN SWING: Press this button once to activate auto up and down swing. Press this button again to cancel. HUMIDIFIER: During operation, press this button to humidify the air, improve the air moisture, avoid dry skin and spall. - Page 7 15. Do NOT use petrol, toluol, etc to clean the unit body. For slight dirt on the body, wipe it off with a soft damp cloth. For greasy dirt, squeeze a little toothpaste or mild detergent on a soft damp cloth, and then wipe the dirt off. 16.
-
Page 8: Maintenance And Cleaning
MAINTENANCE AND CLEANING Note: After long time operation, the filtration mesh becomes clogged with dust and dirt, which will greatly affect the unit’s performance. It is recommended to clean the filtration mesh frequently. Cleaning the filtration mesh 1. Remove plug from wall outlet. 2. -
Page 9: Trouble Shooting
TROUBLE SHOOTING If there is something wrong during operation, it may not be the unit’s probelm. You may check against the following list before sending for repair. Problems Possible reasons Solutions Air flow is weak Notice: 1. If the problem cannot be found in the list or it persists, please contact our service center or a qualified technician for further inspection. - Page 10 For more technical details / enquiries, please visit: EUROPACE SERVICE CENTER 10 Changi South Street 3 #06-01 Singapore 486147 Tel: (65) 6457 3678 | Fax:( (65) 6741 0728 Email: sales@strategic.com.sg www.europace.com.sg www.strategic.com.sg This product is distributed by Strategic Marketing (S) Pte Ltd If there is any technical amendment for the product, it will be edited on the updated version of the instruction manual without prior notice.
