- Page 1 PRODUCT MANUAL TITAN DUAL LEG VERTICAL LIFT WITH HINGED LID OPENER AND FIXED TOP OPTIONS...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TITAN DUAL LEG PARTS LIST..................................... 3 PRODUCT DIAGRAM ................................4 INSTALLATION ..................................7 CABLE MANAGEMENT ................................8 WIRING DIAGRAM ................................9 OPERATION: DPG1C BLUETOOTH ............................10 OPERATION: AUTOMATION ..............................12 TROUBLESHOOTING................................13 SPECIFICATIONS .................................. 14 WARRANTY AND RETURNS ..............................15 MOVING PARTS Do not obstruct the operation of the mechanism with fingers or any object. -
Page 3: Parts List
PARTS LIST TITAN DUAL LEG PARTS LIST Titan Lift with Screen Hanging Rails Hinged Lid Opener (Option 1) Wired Controller Fixed Top (DPG1C Bluetooth) Panel Brackets (Option 2) M6, 16mm Pan Phillips screws QTY: 4 For fastening certain Screens to Hanging Rails 6.4 x 15 x 1.25 Washers QTY: 4 For use with M6x16 Pan Phillips screws... -
Page 4: Product Diagram
PRODUCT DIAGRAM TITAN DUAL LEG PRODUCT DIAGRAM... - Page 5 PRODUCT DIAGRAM TITAN DUAL LEG...
- Page 6 PRODUCT DIAGRAM TITAN DUAL LEG...
-
Page 7: Installation
INSTALLATION TITAN DUAL LEG INSTALLATION TV INSTALLATION: Attach the Screen Hanging Rails to the back of the TV using the correct size screws for your screen as supplied in the Bolt Kit. Ensure Hanging Rails are properly aligned and there is no more than 75mm between the bottom of the TV and the bottom of the Hanging Rails. -
Page 8: Cable Management
CABLE MANAGEMENT TITAN DUAL LEG CABLE MANAGEMENT The Cable Management on the Titan is utilising an Energy Chain articulated cable management system. The Energy Chain will follow the movement of the Titan lift without causing crimping or crushing of cables. The Energy Chain has “doors”... -
Page 9: Wiring Diagram
WIRING DIAGRAM TITAN DUAL LEG WIRING DIAGRAM Below is an image of how the Titan is cabled (showing the DPG1C Bluetooth handheld controller), this should not need to be changed unless swapping to an integrated automation setup using contact closure. Ports and their uses: •... -
Page 10: Operation: Dpg1C Bluetooth
OPERATION: DPG1C BLUETOOTH TITAN DUAL LEG OPERATION: DPG1C BLUETOOTH Follow these instructions if your product has the Bluetooth controller and handset option. DPG1C Controller with Bluetooth LED LIGHTING STRIP REMINDER BLUETOOTH FAVOURITE POSITIONS BEFORE FIRST USE: Download the LINAK “Desk Control” app from your device’s respective App Store. TO SET UPPER LIMIT: Adjust the Lift to the maximum allowable height. - Page 11 OPERATION: DPG1C BLUETOOTH TITAN DUAL LEG TO OPERATE THE LIFT WITH BLUETOOTH HANDSET: • On the Desk Control App, disconnect from the matched device. • To do this, press “More” on the App and then select the matched device. • Select the matched device and press “DISCONNECT”.
-
Page 12: Operation: Automation
OPERATION: AUTOMATION TITAN DUAL LEG OPERATION: AUTOMATION Your product can be integrated into most control systems using dry contact relays. These instructions are provided for Automation specialist reference only. Please contact us, or an Automation specialist, before attempting this change. TO INTEGRATE: Unplug and remove the original controller and replace it with a DP1U Controller. -
Page 13: Troubleshooting
Release the “DOWN” button then press and hold again for 6 seconds. The lift should move up and down slightly. The system is now initialised. If you are still having issues, please contact Ultralift Australia on +61 3 9459 0873 for further support. -
Page 14: Specifications
SPECIFICATIONS TITAN DUAL LEG SPECIFICATIONS MODEL TITAN PART NUMBER TTN-000 MIN LIFT HEIGHT (BOTTOM OF TV) (MM) MAX LIFT HEIGHT (BOTTOM OF TV) (MM) MIN LOAD WEIGHT (KG) MAX LOAD WEIGHT (KG) OPERATING VOLTAGE (V) STANDBY POWER DRAW (W) MAX POWER DRAW (W) DRIVE TYPE ACTUATOR DRIVE QTY... -
Page 15: Warranty And Returns
TITAN DUAL LEG WARRANTY AND RETURNS At Ultralift Australia Pty Ltd, we take pride in the fact that our products are of the highest quality. Because of this, we offer the following programs to ensure your satisfaction. ULTRALIFT 3 YEAR WARRANTY 1.
