7. Install the memory module.
8. Install the base cover.
9. Follow the procedure in

Palm-rest and keyboard assembly

Removing the palm-rest and keyboard assembly

Prerequisites
1. Follow the procedure in
2. Remove the base cover.
3. Remove the memory module.
4. Remove the WLAN card.
5. Remove the solid-state drive in M.2 slot
6. Remove the solid-state drive in M.2 slot
7. Remove the fan.
8. Remove the battery (3-cell
9. Remove the power-adapter
10. Remove the display assembly.
11. Remove the I/O board.
12. Remove the touchpad.
13. Remove the coin-cell
14. Remove the heat sink.
15. Remove the power-button board with optional fingerprint
16. Remove the system board.
NOTE: The system board can be removed along with the heat sink.
17. Remove the speakers.
About this task
After performing the steps in the pre-requisites, we are left with the palm-rest and keyboard assembly.
after working inside your
before working inside your
one.
two.
or 4-cell).
port.
battery.
computer.
computer.
reader.
Removing and installing components 63
