Channel Master CM-4040 Installation Instructions

CM-4040 INDOOR ANTENNA
Easy to install
■
Can receive all UHF channels
■
Ideal for free off-air digital reception
■
Table top or wall mount
■
Complete with 110 in. coaxial cable
■
INSTALLATION INSTRUCTIONS
1. Insert the antenna into the base and assure that the tabs snap
into place (listen for "click").
2. Plug the coaxial connector into the antenna input port of your TV
or digital to analog converter box.
3. For optimum reception, visit www.antennaweb.org to determine
the best direction in which to aim the antenna,
4. Aim the smallest end of the antenna toward the TV transmitters/ towers.
5. Turn your TV (and converter box, if applicable) on and set up your
local digital stations using the on screen menu.
Figure 1
(Figure 1)
Insert tabs here
(Listen for "click")
Underside of Base
Wall Mountable

CM-4040 Dimensions:

10 x 11.5 x 8 in.
(25.40 x 29.21 x 20.32 cm)
www.channelmasterintl.com
Pub PCTCM 200805.CM4040.INST
