Channel Master 1007IFD User Instructions

SATELLITE ACCESSORY
LIMITED NINETY (90) DAY WARRANTY
This Channel Master equipment is warranted to be free from defects in
material and workmanship under normal use and service. Channel Master
shall repair or replace defective equipment, at no charge, or at its option,
refund the purchase price, if the equipment is returned to Channel Master
not more than ninety (90) days after shipment. Removal or replacement of
equipment and its transportation shall not be at the cost of Channel
Master except Channel Master shall return repaired or replaced
equipment freight prepaid.
This Warranty shall not apply to equipment which has been repaired or
altered in any way so as to affect its stability or durability, nor which has
been subject to misuse, negligence or accident. This warranty does not
cover equipment which has been impaired by severe weather conditions
such as excessive wind, ice, storms, lightning or other natural occurrences
over which Channel Master has no control, nor shall this Warranty apply
to equipment which has been operated or installed other than in accor-
dance with the instructions furnished by Channel Master.
Claimants under this Warranty shall present their claim along with the
defective equipment to Channel Master immediately upon failure. Non-
compliance with any part of this claim procedure may invalidate this
Warranty in whole or in part.
This warranty is expressly in lieu of all other agreements and
warranties, expressed or implied, including but not limited to the
implied warranties of merchantability and fitness for a particular
purpose, Channel Master does not authorize any person to assume
for it the obligations contained in this warranty and Channel Master
neither assumes nor authorizes any representative or other person
to assume for it any other liability in connection with the equipment
delivered or provided.
In no event shall Channel Master be liable for any loss of profits, loss
of use, interruption of business, or indirect, special or consequential
damages of any kind.
In no event shall Channel Master be liable for damages in an amount
greater than the purchase price of the equipment.
www.channelmaster.com ©2002 Channel Master LLC (8000865) Printed in China
Model 1007IFD Satellite Signal Meter
with rechargeable battery and charger
INTRODUCTION
The 1007IFD satellite signal meter has been designed for the installation and
maintenance of a satellite TV system. It features signal strength measurement by
both meter indication and audible tone indication for dish antenna peaking. LNB
voltage and current measurement is also provided. An internal, rechargeable
nicad battery pack with output switchable between 13V, 18V, 13V/22KHz and
18V/22KHz allows a dish antenna to be installed prior to installation of the
satellite receiver. The output voltage and 22KHz tone presence from a satellite
receiver may also be monitored. The internal 22KHz generator allows "alternate
satellite" selection on certain types of systems with an integrated LNB/multiswitch.
A 117 VAC wall plug type charger is included.
TECHNICAL SPECIFICATIONS
Frequency range 950-2150MHz
Impedance 75 ohm
Sensitivity (per transponder) -32 to +4 dBm 1 transponder
-41 to -5 dBm 8 transponders
-44 to -8 dBm 16 transponders
Insertion Loss 4dB
Indication Analog Panel Meter 100uA FSD
Acoustic Indicator 0.2 to 5.0KHz
LNB Voltage Measurement 0-25VDC
LNB Current Measurement 0-500mA
Nicad Battery Pack Output 13V, 18V, 13V/22KHz, 18V/22KHz
Tone Output 0.6V square wave, 22KHz
Tone Indicator Requires >300mV, 18-24KHz
Battery Life 3 hours between charges at 170 mA LNB current
Wall Plug Charger Output 24VDC at 100 mA conn. center positive
Charge power/time 24VDC at 60 mA for 12 hours
RF Connectors Type F female
Dimensions H x W x D 3.5" x 6.0" x 4.5" (89 x 152 x 114 mm)
Weight 36 oz. (1032g)
Channel Master ® LLC reserves the right to modify their designs or specifications, in the light of future
developments, without prior notice. The performance figures quoted are typical and are subject to
normal manufacturing and service tolerances.
User Instructions
