- Page 1 Johanna Comby2 Use and maintenance manual 48.41.35.080.GB-07/09 Read the instructions carefully before installation and use of the range cooker.
-
Page 2: Table Of Contents
6.4 The glass gets dirty quickly 6.5 Condensation in the firebox 6.6 The oven does not heat up 6.7 Radiators or central heating system inefficient 6.8 Control unit alarm messages 7 - ATTACHMENTS 7.1 Warranty certificate 7.2 CE marking information Johanna Comby2... -
Page 3: -General Information
The control panel must be switched on during range operation. Cola s.r.l. declines any liability for problems, breakage or accidents caused by failure to follow or apply the instructions contained in this manual. Johanna Comby2... -
Page 4: Technical Description
(optional central heating + domestic hot water module) CO emissions to 13% O 0.674% Recommended quantity of wood per load 2.5/3.5 kg Approx. Firebox capacity litres Weight 278 kg Dimensions (mm) 913 x 1070 x 730 mm (fig. 1) H x W x D = Johanna Comby2... - Page 5 Q- mains water inlet (male ½) R- expansion tank flow (male 1”) S- expansion tank return (male 1”) T- rear flue outlet Dettaglio A U- access hole for screwdriver operated air vent Fig. 1 Johanna Comby range cooker dimensions Johanna Comby2...
-
Page 6: Secondary Air Flow Control
Pulling the lever towards the front of cooker (fig. 2) Oven bypass open Fig.1 forces the flue gases to circulate around the oven, thereby increasing the oven temperature uniformly (position recommended during normal operation). Fig.2 Oven bypass close Johanna Comby2... -
Page 7: Flue Pipe Connection Collar
EN 12815: European standard Norme for cookers fired by solid fuel, containing requirements for design, fabrication, construction, safety and performance , instructions and markings, together with the relative homologation test methods. Standards EN 60335-1 and EN 50165: standards regarding electrical equipment on non-electric appliances. Johanna Comby2... -
Page 8: Dataplate
For the end-user: Contact your service centre and/or dealer to order replacement parts. For the service centre or dealer: To order replacement parts, contact the Cola s.r.l. service centre and/or send a fax clearly specifying the following information: cooker model;... -
Page 9: Installation
The operation of any air extraction device (e.g. fume extractor hood) in the vicinity of the cooker may create a condition of negative pressure in the room, with the consequent leakage of combustion gases from stove when the fire door is opened to load wood. Johanna Comby2... -
Page 10: Advice On Flues And Connections
Roof pitch Distance B Distance A 15° 1.00 m 15° 0.50 m 30° 30° 0.50 m 1.30 m Greater than 1.85 m Less than 1.85 m 45° 2.00 m 45° 0.50 m 60° 2.60 m 60° 0.50 m Johanna Comby2... -
Page 11: Water Connections
If the cooker has to be interfaced with an existing central heating system, to prevent interference between the fluids and pressures of the cooker system and the central heating system, Cola recommends installing an insulated heat exchanger with a power rating of 20-25 kW. - Page 12 The plumbing diagram for the cooker's internal circuit is shown in the figure below. Idraulic diagram of the cooker Cola mod.JOHANNA COMBY rif. Johanna-idr 01-06 Water supplier ½” Domestic circuit esternal cooker Vv=0,05x(Vc+Vi) Vi= tank volume Vc=tubes volume Boiler Johanna Comby Inlet heating circuit (male 1”)
-
Page 13: Electrical Connection
The power supply cable must be connected to a Switched socket. The supply voltage must match that specified on the cooker dataplate and in the technical data section of this manual. Flussostato sanitario Sonda mandata Estrattore fumi Fig. 6 Wiring diagram Johanna Comby2... -
Page 14: Instructions For Use
3 - INSTRUCTIONS FOR USE 3.1 Introduction Never leave children unsupervised in the vicinity of the cooker; there is a very high risk of burns from the hot surfaces. Also: - never use the cooker with the door open; - never store firelighters or other easily combustible materials in the vicinity of the cooker; - never attempt to move or lift the cooker by the handles. -
Page 15: Lighting And Controlling The Fire
3.5 Lighting and controlling the fire With the oven bypass damper set to the open position, and the combustion air controls E and B fully open, set light to some paper or a firelighter with some wood kindling. When the kindling has caught, place a log about 30 cm long on the fire. When the fire is well established, close the oven bypass damper and adjust the combustion air flow control (E) to obtain the desired heat output: position 1 gives a slow burning fire with a moderate heat output, while in position 3 the air flow is increased to obtain a fast burning fire with a high heat output. -
Page 16: Control Panel
4 CONTROL PANEL The figure below shows the control panel and its functions: Display Led deviatore sanitari ON Led pompa acqua ON Led estate Led uscita Ausiliaria ON P1 ON/OFF P4 -Set/menù sblocco P2 -ON/OFF Uscita P3 -Modo estate/inverno ausiliaria -Decremento -Incremento Fig 7 control panel... -
Page 17: Display
4.3 Display During normal operation, the display shows the temperature of the firebox water During operation of the domestic hot water system, displays the message DHW In temperature and parameter setting mode, shows the name of the parameter currently being set. 4.4 User functions 4.4.1 Turning the cooker on and off Press button P1 for one second to switch on the control panel for the water heating module. -
Page 18: Maintenance And Care
4.5 BUZZER If the temperature rises above 80°C, the control unit will emit an audible beep and the display will flash to warn the user of overheating. 5. MAINTENANCE AND CARE To maintain the cooker in good working order it is good practice to regularly clean the exterior and internal parts where there is buildup of soot , which, in addition to blocking the air flow and thus impairing efficiency, can sometimes also catch fire. -
Page 19: Cleaning The Oven
1” M. 9.8 CH circulating pump 9.9 DHW circulating pump 9.10 Pressure relief valve for CH system (p>3 bar) 9.11 Air vent (screwdriver operated) 9.12 Ball valve with union for circulating pump, 1”F (screwdriver operated) Johanna Comby2... -
Page 20: Troubleshooting
50-60° C. 6.8 Control unit alarm messages Temperature > 80 ° C with emission of audible alarm until temper ature falls and display of message ‘Alr’; reduce temperature both by closing the primary air control and the thermostat. Johanna Comby2... - Page 21 Email: info@anselmocola.com On-line: www.anselmocola.com The company reserves the right to make technical or aesthetic modifications to the products at any time without notice. The drawings, measurements, diagrams and any other configurations are given only by way of example. Johanna Comby2...
-
Page 22: Ce Marking Information
5,5 kW Rendimento 73 % Energy efficiency Tipi di combustibile Legna in tronchetti Fuel types Wood logs Potenza elettrica 180 W Rated input power Tensione nominale 230 V Rated voltage Frequenza nominale 50 Hz Rated frequency Johanna Comby2...
