Chamberlain Security+ 963CD Owner's Manual

Model 963CD Security✚
For use with 315MHz Security✚
universal receivers that have a purple "learn" button and
315MHz gate receivers.
NOTE: To activate the remote control functions, pull out the plastic
pull tab protruding from the remote control housing.
This remote control is equipped with a proximity lighting feature.
When moving a hand within close proximity to the remote control,
the LED lights turn on for 3 seconds. Upon successful activation
of a remote control button, the LED lights will blink rapidly.
Proximity Disable Feature
The remote control will turn off the proximity lighting feature if the
proximity lighting is turned on 10 consecutive times without
activation of a button. To re-enable the proximity lighting, simply
press a button. This function conserves battery life.
To Add or Reprogram the Remote Control
1. Press and release the "learn" button on the
motor unit. The learn indicator light will
glow steadily for 30 seconds.
2. Within 30 seconds, press and hold the
button on the hand-held remote.
3. Release the button when the motor unit
light blinks. It has learned the code. If light
bulbs are not installed, two clicks will be
heard.
To Erase All Codes From Motor Unit Memory
To deactivate any unwanted remote, first erase all codes:
Press and hold the "learn" button on motor unit
until the learn indicator light goes out
(approximately 6 seconds). All previous codes
are now erased. Reprogram each remote or
keyless entry you wish to use.
with Proximity Lighting Feature
OWNER'S MANUAL
®
garage door openers and
9
1 9 1
7 5 3 7 3
5
KG KG
OR
®
3-Button Remote Control
To prevent possible SERIOUS INJURY or DEATH from a moving gate
or garage door:
• ALWAYS keep remote controls out of reach of children. NEVER
permit children to operate or play with remote control transmitters.
• Activate gate or door ONLY when it can be seen clearly, is properly
adjusted and there are no obstructions to door travel.
• ALWAYS keep gate or garage door in sight until completely closed.
NEVER permit anyone to cross path of moving gate or door.
To Control the Opener Lights
NOTE: Feature only available on openers equipped with a
multi-function control panel.
With 315MHz Security✚
can be programmed to operate the opener lights without opening
the door.
1. With the door closed, press and hold the remote button that
you want to control the light.
2. Press and hold the Light button on the multi-function control
panel.
3. Press and hold the Lock button on the multi-function control
panel.
4. After the opener lights flash, release all buttons.
Test by pressing the remote push button. The opener lights
should turn on or off but the door should not move.
Open/Close/Stop Operation
NOTE: Feature only available on openers equipped with a
multi-function control panel.
Your 315MHz Security✚
operate one door using all 3 buttons: the button with one light slot
will only open the door, the button with two light slots will close
the door, and the button with three light slots will stop the door's
movement. You may set up this feature as follows:
1. With the door closed, press and hold the button with one light
slot.
2. Press and hold the Lock
button on the multi-function
control panel.
3. Press and hold the main door
control push button.
When the opener lights flash,
release all buttons. Test by pressing the 1 light slot button (Open)
on the remote. The door should open. Press it again while the
door is open and nothing should happen. Press the 2 light slot
button (Close) while the door is moving and it should close. Press
the 3 light slot button (Stop) and the door should stop
immediately.
®
®
remote controls, a remote push button
®
remote control can be programmed to
3 Light Slots
(Stop)
1 Light Slot
(Open)
2 Light Slots
(Close)
