HealTech Electronics Glpro Mount Instruction Manual

GIpro Mount
Instructions manual
Fully adjustable handlebar mount for GIpro
Choose the proper shim
Thick
Disassemble the clamp. Separate the plastic shims
and unroll the thin shim. Depending on the target
tube diameter, select the right shim and place on the
handlebar.
21-23mm (7/8") : Thick Shim
24-26mm (1")
27-29mm (9/8") : Without Shim
Insert the pin
Slide the pin in place, making sure the threaded hole is
aligned with the bolt hole.
Thin
: Thin Shim
w w w . h e a l t e c h - e l e c t r o n i c s . c o m
Place the clamp on the bar
Wind the arm around the target tube then close.
If a plastic shim is used, rotate it into proper position.
Fasten the clamp
Tighten the bolt with an
M5 hex (Allen) wrench
to secure the clamp on
the bar in the desired
position.
