SRP-14-GB(V3)
IMPORTANT SAFETY RULES
READ, UNDERSTAND, AND FOLLOW ALL INSTRUCTIONS CAREFULLY
BEFORE INSTALLING AND USING THIS PRODUCT !
Rectangular Steel Frame Pool
OWNER'S MANUAL
FOR FOLLOWING SIZES:
-10'x6,8'x27,6" (3mx2.07mx70 cm)
-74"x50"x16,5"(1.88mx1.27mx42 cm)
-13'x6,8'x31,5" (3.94mx2.07mx80 cm)
-90"x62,6"x16,5"(2.28mx1.59mx42 cm)
-8,5'x6'x26" (2.58mx1.79mx66 cm)
Drawing for illustration purpose only. Actual product may vary. Not to scale.
DO NOT RETURN PRODUCT TO STORE
STOP!
CONTACT YOUR LOCAL AFTER SALES SERVICE CENTER
READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE!
1
Advertisement
Table of Contents
Related Manuals for Jilong JL016101NG
Summary of Contents for Jilong JL016101NG
- Page 1 SRP-14-GB(V3) IMPORTANT SAFETY RULES READ, UNDERSTAND, AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING AND USING THIS PRODUCT ! Rectangular Steel Frame Pool OWNER’S MANUAL FOR FOLLOWING SIZES: -10’x6,8’x27,6” (3mx2.07mx70 cm) -74”x50”x16,5”(1.88mx1.27mx42 cm) -13’x6,8’x31,5” (3.94mx2.07mx80 cm) -90”x62,6”x16,5”(2.28mx1.59mx42 cm) -8,5’x6’x26” (2.58mx1.79mx66 cm) Drawing for illustration purpose only.
-
Page 2: Table Of Contents
SRP-14-GB(V3) CONTENTS IMPRTANT SAFETY RULES------------------------------------------------------------------------------------02 PART REFERENCE------------------------------------------------------------------------------------------------04 SITE SELECTION---------------------------------------------------------------------------------------------------08 SET UP THE POOL-----------------------------------------------------------------------------------------------09 FILL THE POOL WITH WATER--------------------------------------------------------------------------------10 DISASSEMBLY AND STORAGE -----------------------------------------------------------------------------11 IN-SEASON POOL MAINTENANCE AND WATER CARE-------------------------------------------12 TROUBLE SHOOTING ------------------------------------------------------------------------------------------13 LIMITED WARRANTY ------------------------------------------------------------------------------------------ 14 PART1-IMPORTANT SAFETY RULES WARNING To enhance the enjoyment of your pool and protect the safety of those in and around the pool, ALWAYS STRICTLY OBSERVE the following safety and maintenance instructions: 1). - Page 3 SRP-14-GB(V3) PART1-IMPORTANT SAFETY RULES - Supervision of children must be close and constant; - Designate one responsible for security; - Strengthen monitoring when there are multiple users in the pool; - Teach your children to swim as soon as possible; - Wet neck, arms and legs before entering the water;...
-
Page 4: Part Reference
SRP-14-GB(V3) PART2-PART REFERENCE 13’x6,8’x31,5” (3.94mx2.07mx80 cm) Before assembling your pool, layout and review the contents to become familiar with all the parts you will be using during the assembly: NOTE: Drawing for illustration purpose only. Actual product may vary. Not to scale. 13’x6,8’x31,5”... - Page 5 SRP-14-GB(V3) PART2-PART REFERENCE 10’x6,8’x27,6” (3mx2.07mx70 cm) NOTE: Drawing for illustration purpose only. Actual product may vary. Not to scale. 10’x6,8’x27,6” (3mx2.07mx70 cm) NAME QUANTITY SERIAL NUMBER QUANTITY SERIAL NUMBER 290256 393021 Horizontal Beam A 290257 393022 Horizontal Beam B 290252 393028 T-Joint 290258...
- Page 6 SRP-14-GB(V3) PART2-PART REFERENCE 8,5’x6’x26” (2.58mx1.79mx66 cm) NOTE: Drawing for illustration purpose only. Actual product may vary. Not to scale. 8,5’x6’x26” (2.58mx1.79mx66 cm) NAME QUANTITY SERIAL NUMBER 290249 Horizontal Beam A 290250 Horizontal Beam B 290249 Horizontal Beam C 290250 Horizontal Beam D 290252 T-Joint 290251...
- Page 7 SRP-14-GB(V3) PART2-PART REFERENCE 90”x62,6”x16,5”(2.28mx1.59mx42 cm) 74”x50”x16,5”(1.88mx1.27mx42 cm) NOTE: Drawing for illustration purpose only. Actual product may vary. Not to scale. 90”x62,6”x16,5”(2.28mx1.59mx42 cm) 74”x50”x16,5”(1.88mx1.27mx42 cm) NAME QUANTITY SERIAL NUMBER NAME QUANTITY SERIAL NUMBER Horizontal Beam 290245 290239 Horizontal Beam A Horizontal Beam 290246 290240 Horizontal Beam B...
-
Page 8: Site Selection
SRP-14-GB(V3) PART3-SITE SELECTION WARNING: Pools installed on inadequately level surfaces are subject to leaking, forming irregularities, or collapse, which can result in property damage or serious in- jury for those in or around the pool area! WARNING: Do not use sand during setup process. If it appears that there is a need for use of a “leveling agent”, then your set-up site is likely unsuitable. -
Page 9: Set Up The Pool
SRP-14-GB(V3) PART4-SET UP THE POOL IMPORTANT: Do not start assembly if any pieces are missing. For replacement pieces call the Consumer Service telephone number in your area. The number of persons required for installation: 2 adult at least. Total installation time except the time for site preparation and water filling : 45 minutes for size 10’×6.8'×27.6"/13'×6.8'×31.5";... -
Page 10: Fill The Pool With Water
SRP-14-GB(V3) PART4-SET UP THE POOL Step4. INSTALL L-JOINT 1. Use the connection end of the L-JOINT to connect the adjacent horizontal tubes. 2. Use the connection end of the L-JOINT to connect the vertical leg. (Install the vertical leg cap on the leg before.) 3. -
Page 11: Disassembly And Storage
SRP-14-GB(V3) PART6-DISASSEMBLY AND STORAGE WARNING: Do not let your children stand at downfold and face the water outlet during the drainage. The water current may sweep your children. WARNING: Pool should be stored at places where is cool and dry, with no sharp object surroued, or no heavy objects lying above, which may cause damage to the pool. -
Page 12: In-Season Pool Maintenance And Water Care
SRP-14-GB(V3) PART7-IN-SEASON POOL MAINTENANCE AND WATER CARE WARNING: If applicable, the filter pump included with your pool is designed to remove dirt and other small particles from your pool water. However, to maintain pool water that is perfectly clear, algae free, and safe from harmful bacteria, it is VERY IMPORTANT TO ENGAGE IN A CONSISTENT REGIMEN OF CHEMICAL TREATMENT. -
Page 13: Trouble Shooting
SRP-14-GB(V3) PART7-IN-SEASON POOL MAINTENANCE AND WATER CARE your local after sale service center if you want to get advice on any repair during the life of the pool kit. 4. If applicable, check your filter-pump cartridge every two weeks (or more frequently during periods of heavy usage) to verify whether it needs to be cleaned or replaced. -
Page 14: Limited Warranty
This limited warranty, furthermore, does not cover any unauthorized alterations to the product. Model Size Water Capacity Pump Ladder JL016101NG/NF/NN/ND/NC 8,5’x6’x26” (2.58mx1.79mx66 cm) 690Gal(2612L) √ × JL016101N 8,5’x6’x26” (2.58mx1.79mx66 cm) 690Gal(2612L) ×...
