- Page 1 Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation SB-WM32D SB-WM32NA SB-WM32 All-Weather Flat Panel Wall Mounts Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description SB-WM32 Series...
-
Page 2: Important Safety Instructions
DISCLAIMER WARNING: Never operate this mounting system if it is SunBriteTV LLC (SBTV) intend to make this manual accurate damaged. Return the mounting system to a service center for and complete. However, SBTV makes no claim that the examination and repair. - Page 3 Installation Instructions SB-WM32 Series DIMENSIONS SB-WM32NA 85.07 3.35 152.40 6.00 81.77 3.22 3.94 58.57 2.31 3.94 211.43 120.65 8.32 4.75 175.87 134.32 6.92 5.29 SB-WM32 332.93 13.11 300.97 11.85 80.36 3.16 152.40 6.00 81.77 3.22 3.94 139.62 3.94 5.50 292.47 215.36...
- Page 4 SB-WM32 Series Installation Instructions DIMENSIONS (CONTINUED) SB-WM32D 516.87 20.35 307.72 215.90 215.90 12.11 8.50 8.50 152.40 81.77 6.00 3.22 68.25 2.69 231.52 9.11 26.20 1.03 3.94 3.94 220.66 8.69 373.33 14.70 120.65 4.75...
-
Page 5: Tools Required For Installation
Installation Instructions SB-WM32 Series LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación... -
Page 6: Installation
Use a stud finder to locate wood stud. IMPORTANT ! : The SB-WM32 Series mounts are designed to be mounted to a 2" x 4" wood studs wall. Using wall plate (D) as a template, mark then drill two 1/4"... -
Page 7: Display Installation
It is the installer’s responsibility to make sure the combined weight of all components located between the SB-WM32 Series mount up to (and including) the display does not exceed 75 lbs (34 kg). -
Page 8: Cable Management
SB-WM32 Series Installation Instructions Align two screws in display back with upper teardrop mounting holes in mounting plate and lower display until screws are seated in lower area of teardrop mounting holes. (See Figure 5) Cable Path CAUTION: Do not let go of the television at this point. Hold... - Page 9 Installation Instructions SB-WM32 Series...
- Page 10 SB-WM32 Series Installation Instructions...
- Page 11 Installation Instructions SB-WM32 Series...
- Page 12 SB-WM32 Series Installation Instructions SunBriteTV, LLC 2001 Anchor Court Thousand Oaks, CA 91320 866-357-8688 www.sunbritetv.com 8800-002163 Rev00 04/12...
