Page 2: Product Overview
Microphone Micro-USB MicroSD Card Power Port Slot (Visible Microphone Loudspeaker when lens is facing upward) Reset Button Reset Front View Rear View Package Contents: Mi 360° Home Security Camera 2K Pro, power adapter, charging cable, wall mounting kit, user manual... -
Page 3: Installation
Installation The Mi 360° Home Security Camera 2K Pro can be placed on horizontal surfaces, such as desks, dining tables, and coffee tables. It can also be mounted on a wall. Mounting the camera on a wall: 1. First use a pencil to mark the positions for the base mounting holes on the wall, then drill two holes at the marked positions. - Page 4 3. Place the side of the base with arrows facing forward, and then align the holes. Insert the screws and then tighten them into the wall plugs with a Phillips head screwdriver. 4. Align the grooves on the bottom of the camera with the raised part on the base, and then turn it clockwise until it locks into place.
-
Page 5: How To Use
How to Use Installing a MicroSD card Make sure the camera is turned off. Push the lens upward to reveal the MicroSD card slot. Insert the microSD card into the card slot with its contact points facing downward. Note: Disconnect the camera from the power before installing or removing a MicroSD card. - Page 6 Note: When the camera is working, do not turn the lens of the camera nor force it to rotate. If the positioning of the lens is inaccurate, please calibrate it in the Mi Home/Xiaomi Home app. Indicator Blue: Connected successfully/Working properly...
- Page 7 Restoring factory settings In case the network the camera is connected to, or the Mi account the camera is paired with has to be changed, use a pin to press and hold the reset button for about five seconds to restore factory settings.
-
Page 8: Real-Time Surveillance
Real-time Surveillance In the app, you can view the real-time surveillance, adjust the sharpness of the image, adjust the horizontal and vertical angles, capture and record, and make calls. Infrared Night Vision The camera can automatically switch to night vision mode at night according to the change in ambient light. - Page 9 Home Surveillance Assistant When the home surveillance assistant is enabled, the camera will record videos if it detects human movement and changes in real-time within its surveilled area. Then you will get the app push notification. You can enable or disable the function of automatic surveillance in the app. You can set 24-hour, daytime, nighttime, custom period surveillance, alert sensitivity and alert time intervals, etc.
-
Page 10: Video Sharing
In the app, you can select the device sharing option in the settings menu to share the camera with others. The users, you share the camera with, need to download the Mi Home/Xiaomi Home app and log in with their Mi account to view contents. - Page 11 Precautions The operating temperature range for this camera is between -10°C and 40°C. Do not use the camera in environments with temperatures above or below the specified range. The camera is a precision electronic product. In order to ensure its normal operation, do not install the camera in environments with high humidity levels nor allow water to get into it.
-
Page 12: Weee Information
EU Declaration of Conformity Hereby, Shanghai Imilab Technology Co., Ltd. declares that the radio equipment type Mi 360°Home Security Camera 2K Pro is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address:... -
Page 13: Specifications
Na Roudné 1162/76, 301 00 Plzeň www.beryko.cz For further information, please go to www.mi.com Manufactured by: Shanghai Imilab Technology Co., Ltd. (a Mi Ecosystem company) Address: Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang District, Shanghai, China...
