LORUS R23 YK35 Instruction Manual

NREYK35C
■ C H A R A C T E R I S T I C S
1. T i m e / C a l e n d a r d i s p l a y : H o u r , m i n u t e ,
second, date, day of the week and month
are displayed.
2. Stopwatch: The stopwatch can measure up
to 24 hours in 1/100-second increments for
t h e f i r s t 3 0 m i n u t e s , a n d i n 1 - s e c o n d
i n c r e m e n t s
measurement is available.
3. Alarm: The alarm can be set to ring at a
designated time.
4. Electro Luminescent Backlight: The built-in
electro luminescent backlight illuminates the
display for easy viewing in the darkness.
■ D I S P L AY A N D B U T T O N O P E R AT I O N
D a y o f t h e w e e k
D
C
Button operation from normal Time Display
To turn the backlight on,
press Button
To change mode,
press Button
* T h e r e i s n o B u t t o n E f o r C a l . Y K 3 6 .
■ H O W T O S E T T H E T I M E / C A L E N D A R
The setting sequence is shown below.
Second
Day of
the week
1. Press Button C three times to enter the Time
S e t t i n g m o d e . T h e s e c o n d d i g i t s s t a r t
flashing.
The "2" appears on the display to indicate
that the watch is in the Time Setting mode.
* For Cal. YK36, different indicators appear
o n d i s p l a y .
2. Press Button A simultaneously with a time
signal to reset the second digits to zero. The
second digits instantly start counting.
C
* When the second digits are counting any
number between "30" and "59" and Button
A is pressed, the second digits are reset to
zero and one minute is added.
3. Press Button B to confirm the second setting
and move on to the minute setting. The
minute digits start flashing.
4. Press Button A to adjust the minute digits.
* Keep Button A pressed to forward the digits
rapidly.
5. Press Button B to confirm the minute setting
and move on to the hour setting. The hour
digits start flashing.
6. Press Button A to adjust the hour digits.
* When setting the hour, make sure that am/
pm is set correctly.
7. Press Button B to confirm the hour setting and
move on to the date setting.
8. Repeat the same procedures for all other
settings; press Button A to adjust digits and
press Button B to confirm the setting and
move on to the nest setting.
9. After all the adjustments are completed,
press Button C to return to the Time display.
■ H O W T O U S E T H E S T O P WAT C H
The stopwatch can measure up to 24 hours in
1/100-second increments for the first 30 minutes,
and in 1-second increments thereafter.
C
Standard Measurement
1. Press Button C to enter the Stopwatch mode.
2. Press Button A to start timing.
3. Press Button A to stop.
4. Press Button B to reset the stopwatch to zero.
5. To exit the Stopwatch mode and return to
the Time display, press Button C.
Lap Time Measurement
1. Press Button C to enter the Stopwatch mode.
2. Press Button A to start timing.
3. To view lap time, press Button B while the
stopwatch is counting. Lap time is shown on
the display while the stopwatch continues to
count internally.
4. Press Button B again to go back to the display
of the measurement in progress.
5. Press Button A to stop timing.
6. Press Button B to reset the stopwatch to zero.
7. To exit the Stopwatch mode and return to
the Time display, press Button C.
* Lap time readings can be repeated by
pressing Button B.
CAL. YK35, YK36 (R23 SERIES)
t h e r e a f t e r .
H o u r
E
or
D
E
Normal
Time
Display
To show the alarm time,
press Button
C
Minute
Month
3-2005
L a p t i m e
M i n u t e
A
B
S e c o n d
To show the date,
press Button
A
B
Hour
Date
A
B
A
B
