Tumble Dryer
Thank you for your trust and for buying our tumble drier. We hope it will successfully
This appliance was designed for drying clothes,
for home use only.
Laundry dried in the tumble drier is dried quickly,
is soft and smooth and does not change the
shape during drying. With a tumble drier, there is
no need for an extra room and no need for ropes
and waiting for a sunny day.
Instructions for Use should be of some help
to you therefore it is recommendable to read
Before Use ...................................................... 12
Useful Hints
Important Warnings ..................................... 13
Positioning And Installation ......................... 13
Door ................................................................ 15
Description Of The Appliance........................ 15
Extractor dryer
Extractor dryer
Drying............................................................. 16
Before Use
Wipe the interior of the drum with soft cloth and
liquid detergent. Do not use aggressive cleaning
agent which could damage the surface. Load the
appliance with old wet clothes and set the drying
time to 45 minutes.
WHEN YOU FIND YOUR APPLIANCE IS OUT
OF USE AND NO LONGER NEEDED, TRY NOT
TO BURDEN THE ENVIRONMENT WITH IT.
CALL YOUR NEAREST AUTHORIZED
"COLLECTING SERVICE FOR USED
APPLIANCES".
12
serve its purpose for many years.
them carefully and to keep in an adequate
place. All warnings on safe use of the dryer
should be considered.
Instructions for Use have been prepared for
different models of tumble dryers. Only
descriptions applying to your type of dryer
whether venting or condenser-type should be
considered
Cleaning And Maintenance........................... 18
Trouble Shooting Guide................................ 19
Useful Hints
Instructions for Use
Drying a large quantity of laundry is not
recommended because it will remain creased
and unevenly dried (max. 5 kg of dry resistant
laundry is recommended).
Drying very delicate laundry (woolens, silk
garments) is not recommended as they may
shrink or lose shape.
Synthetic curtains, fabrics with metal threads,
nylon stockings, as well as lingerie with
prevailing foam rubber components or rubber-
like
materials,
should
EN
be
dried
at
low
Advertisement
Table of Contents
Related Manuals for Gorenje WT840
Summary of Contents for Gorenje WT840
- Page 1 Tumble Dryer Thank you for your trust and for buying our tumble drier. We hope it will successfully serve its purpose for many years. This appliance was designed for drying clothes, them carefully and to keep in an adequate for home use only. place.
- Page 2 temperature setting (delicate laundry programs When buying clothes, especially underwear, do or time setting programs). not forget that they shrink during washing as Put delicate laundry into a special sack, when well as during drying. drying together with other laundry. Clothes marked with a "no tumble dry"...
- Page 3 Vent pipe can be bought in any technical store (identification code PIPE SP-377628). B - Condenser - type Dryer Do not install the condenser dryer into the room where a danger of freezing can occur. Freezing of water in the condensed water drawer and the pump can damage the appliance.
- Page 4 Door Door of the dryer can be opened by pressing the Be careful not to pinch the laundry with the door door frame against the machine, as shown in the as it might get damaged. figure. The door is closed in the same way, If the door is not closed properly the machine will not operate.
- Page 5 Drying Drying programme selection clements are fited in the control panel as well as the indicator light which is on during the operation of the machine. Preparing the Laundry for Drying Sort the laundry before drying according to type of the laundry. Do the buttons, zippers, join the strings and pull Switching ON/Switching OFF out the pockets.
- Page 6 Venting fissures and the opening on the front or Drying Time on the rear side of the dryer must be free. After cleaning, close the door of the dryer so that the Drying time depends number drum light will turn off. (models with illuminated revolutions when spinning the laundry in the drum).
- Page 7 Cleaning and Maintenance Before cleaning, disconnect the appliance from drying in the machine. When drying the laundry power supply. out in the open, the fluff is carried away by the wind. Housing Cleaning of extractor dryer Wipe the housing with a soft wet cloth and mild cleaning agent.
- Page 8 WARNING! Water from the condenser receptacle is not for drinking! Cleaning the Air-cooler Check the air cooler occasionally, and remove any accumulated fluff particles. Pull the handle off the air cooler and remove it. Rinse it on both sides with lukewarm water eliminate...
