50W DALI DT6 DIMMABLE LED DRIVER
•
DT6 dimmable 1/2-channel TW power supply unit
•
200-240VAC wide input voltage range
•
1/2-channel constant current output (total output power up to 50W)
•
Output current from 250mA to 1500mA selectable via DIP switches
•
Class 2 power supply, completely insulated plastic housing
•
High power factor and efficiency
•
Built-in DALI interface, DALI DT6 device, the device can be controlled via 1/2 DALI address
•
Colour control according to DALI DT6 specifications
•
Complies with DALI IEC 62386-101,102,207 standard
•
Generally compatible with DALI masters supporting DT6 commands
•
IP20 protection class, suitable for indoor lighting projects
•
5 years warranty
Änderungen vorbehalten. Angaben ohne Gewähr. / 05.06.2019 © Simpex Electronic
SRP-2305-50-TW-CC
Product features
1
Advertisement
Table of Contents
Related Manuals for Simpex Electronic SRP-2305-50-TW-CC
Summary of Contents for Simpex Electronic SRP-2305-50-TW-CC
- Page 1 Colour control according to DALI DT6 specifications • Complies with DALI IEC 62386-101,102,207 standard • Generally compatible with DALI masters supporting DT6 commands • IP20 protection class, suitable for indoor lighting projects • 5 years warranty Änderungen vorbehalten. Angaben ohne Gewähr. / 05.06.2019 © Simpex Electronic...
- Page 2 I/P-O/P: 100M Ohms / 500VDC / 25°C / 70% RH EMC Emission EN55015, EN61000-3-2, EN61000-3-3 EMC Immunity EN61547, EN61000-4-2,3,4,5,6,8,11, 193.6K hrs min. @ 230VAC full load and 25°C MTBF Others 210*50*32mm (L*W*H) Dimension Warranty 5 years Änderungen vorbehalten. Angaben ohne Gewähr. / 05.06.2019 © Simpex Electronic...
- Page 3 Note: Simpex is just responsible for the product itself and not for consequential damages or costs. Extended warranty requirements have to be agreed case by case. The general terms and conditions of the Simpex Electronic AG apply (https://www.simpex.ch/en/Imprint/). Änderungen vorbehalten. Angaben ohne Gewähr. / 05.06.2019 © Simpex Electronic...
- Page 4 The DALI address can also be programmed automatically via a master. Please refer to the operating instruc- tions of the respective DALI master. Information: The display will show AU if the DALI Master assigns the address to the device. Änderungen vorbehalten. Angaben ohne Gewähr. / 05.06.2019 © Simpex Electronic...
- Page 5 Note: Simpex is just responsible for the product itself and not for consequential damages or costs. Extended warranty requirements have to be agreed case by case. The general terms and conditions of the Simpex Electronic AG apply (https://www.simpex.ch/en/Imprint/). Änderungen vorbehalten. Angaben ohne Gewähr. / 05.06.2019 © Simpex Electronic...
