Sealey SCFS04 Instructions

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to
instruction
manual
1. safetY
WarninG! this safe is heavy (33.5kg) and care should be exercised in transit and handling to ensure that no one is injured.
‰
Do not drill holes in the casing for fixing purposes, this could undermine fire resistance. This is a free standing safe.
8
Do not install in areas where damp and condensation may be present, underground or cellars for example.
8
WarninG! The warnings, cautions and instructions referred to in this instruction manual cannot cover all possible conditions and
‰
situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this product,
but must be applied by the operator.
2. introDuction
Heavy-duty *ABS shell with four bolt door locking mechanism. Dual wall filled with **cellular concrete for fire resistance and thermal insulation.
Electronic panel with LCD screen, accepts thousands of 6 digit codes. •Also supplied with two emergency override keys. Offers up to one hour fire
resistance with UL approval.
• Keep the cabinet key and any record of the code separate from the cabinet and unidentified.
* ABS Flame Retardant with UL 94 VO High Classification for strength and impact resistance.
** Cellular concrete is a non-flammable solid building material which belongs to building material category A1, offering a shield against
heat in the event of a fire.
3. specification
model no: ..................................................................SCFS04
external size (W x d x H): .......................450 x 380 x 190mm
internal size (W x d x H): ........................340 x 245 x 190mm
Wall /door thickness: ............................................... 55/82mm
Weight: ........................................................................ 33.5kg
4. installation
4.1. Consideration should be given to the placing of the safe to ensure that it is placed in a discreet location and will not be easily found by
intruders.
© Jack Sealey Limited
instructions for
electronic fire proof safe
450 x 380 x 305mm
scfs04
model no:
fig.1 fig.2
Original Language Version
red button
Battery compartment
depress tab and lift
off cover.
sCFS04| Issue 3 (L) 20/04/17
