Thank you for choosing Air Conditioners, please read this owner's manual carefully before
operation and retain it for future reference.
Multi Variable Air Conditioners
Duct Type Indoor Unit
Owner's Manual
Air Conditioners
Models:
AMV5-22SLD AMV5-25SLD
AMV5-28SLD AMV5-32SLD
AMV5-36SLD AMV5-40SLD
AMV5-45SLD AMV5-50SLD
AMV5-56SLD AMV5-63SLD
AMV5-72SLD
Advertisement
Table of Contents
Related Manuals for Asami AMV5-22SLD
Summary of Contents for Asami AMV5-22SLD
- Page 1 Multi Variable Air Conditioners Duct Type Indoor Unit Owner's Manual Air Conditioners Models: AMV5-22SLD AMV5-25SLD AMV5-28SLD AMV5-32SLD AMV5-36SLD AMV5-40SLD AMV5-45SLD AMV5-50SLD AMV5-56SLD AMV5-63SLD AMV5-72SLD Thank you for choosing Air Conditioners, please read this owner’s manual carefully before operation and retain it for future reference.
- Page 3 Preface For correct installation and operation, please read all instructions carefully. Before reading the instructions, please be aware of the following items: 1) Execution standard of AMV Multi VRF: ISO 15042-2011. 2) For the safe operation of this unit, please read and follow the instructions carefully. 3) During operation, total capacity of indoor units should not exceed the total capacity of outdoor units.
-
Page 4: Table Of Contents
Contents 1 Safety Precautions ........................1 2 Product Introduction ........................3 2.1 Names of Key Components ....................3 2.2 Rated Working Condition ....................3 2.3 Unit Functions ........................3 3 Preparations for Installation ......................3 3.1 Standard Fittings........................ 3 3.2 Location for Installation ...................... 4 3.3 Requirements for Communication Line ................ -
Page 5: Safety Precautions
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit 1 Safety Precautions Means items that must be forbidden! Otherwise, it may lead to personal injury or death or serious damage. Means items that must be followed! Otherwise, it may lead to personal injury or property loss. Installation should be Follow this instruction to conducted by dealer or... - Page 6 Fault service may unit and cut off the main cause electric shock or fire power supply, and then accidents. Please contact immerdiately contact ASAMI ASAMI appointed service appointed service center.If center for help. abnormality keeps going, the unit might be damaged and lead to electric shock or fire.
-
Page 7: Product Introduction
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit 2 Product Introduction 2.1 Names of Key Components ① ② ③ ④ ⑤ Name Drain Pipe Electric box Hooker Air Outlet Air-return Opening 2.2 Rated Working Condition Indoor Side Condition Outdoor Side Condition Dry Bulb Temp °C Wet Bulb Temp °C... -
Page 8: Location For Installation
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Name Graphics Quantity Purpose wire controller package (including wire controller, emergency bottom case, 1set Control indoor unit instruction manual, screws, packing box) optional parts (including Remote controller 0 or 1 #7 batteries) wrap water pipe and Sponge for drainage pipe... -
Page 9: Requirements For Communication Line
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Notes: ①Installation of the unit must be in accordance with National Electric Codes and local regulations. ②Improper installation will affect unit’s performance, so do not install the unit by yourself. Please contact local dealer to arrange professional technicians for the installation. -
Page 10: Wiring Requirements
Equip with a service port after lifting the unit. For the convenience of maintenance, the service port should be on one side of the electric box and below unit’s lower level. Below are the outline dimension applicable to indoor units of AMV5-22SLD, AMV5-25SLD, AMV5-28SLD, AMV5-32SLD, AMV5-36SLD, AMV5-40SLD,AMV5-45SLD, AMV5-50SLD,... - Page 11 Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Fig 4.1.1 Below are dimensions of A, B, C, etc. for different models: Unit: mm Item Model AMV5-22SLD AMV5-40SLD 1060 1000 AMV5-72SLD 1360 1300 4.1.2 Punching of Bolt Spots and Bolt Installation Punch holes on the installation area according to the 4 spots on the paper pattern;...
- Page 12 Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Fig 4.1.3 Notes: The length of bolt depends on the installation height of the unit, bolts are field supplied. 4.1.3 Lift the Unit Lift up the unit to the ceiling and secure it on the bolt. Use specialized nut to secure the unit. Fig 4.1.4 Notes : ①Before installation, please finish the preparation work of all pipes (connection pipe, drain pipe) and...
-
Page 13: Pipe Connection
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Fig 4.1.5 4.2 Pipe Connection （1） Direct the flaring of copper pipe to the center of screwed connection and then screw the flaring nut tight as shown in Fig.4.2. （2） Use a torque wrench to tighten up the flaring nut until the wrench gives out a click sound. Torque for tightening nut Pipe diameter (mm) Torque (N·m) - Page 14 Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit （ 1 ） Insert the drain hose into the drain hole and tighten it with tapes, as shown in Fig 4.3.2. （ 2 ） Tighten the pipe clamp, with the distance between screw nut and hose smaller than 4mm. ①metal clamp(accessory) ②drain hose(accessory) （...
- Page 15 Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Fig 4.3.6 Fig 4.3.7 Fig 4.3.8 NO1: Connection of drainage pipe joints (Fig4.3.6) NO2: Connection of downspout elbow (Fig4.3.7) NO3: Inserting pipe connection (Fig4.3.8) The installation height of raising pipe for drainage should be lower than 850mm. The gradient from raising pipe towards drainage direction should be at least 1%~2%.
-
Page 16: Installation Of Air Duct
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit connection pipe. Arrange insulation of drain hose and pipe clamp after checking the drain system. Models with water pump Fill some water to the water tray of indoor unit as following. 1) Connect the drain hose to the other drain connection pipe of water tray and fill about 1L water (as shown in 4.3.11). - Page 17 Hanger Rod Diffuser Connector Supply Air Outlet 4.4.2 Shape and Size of Air Outlet and Air-return Opening The following figure is applicable for the models below: AMV5-22SLD, AMV5-25SLD, AMV5-28SLD, AMV5-32SLD, AMV5-36SLD, AMV5-40SLD, AMV5-45SLD,AMV5-50SLD,AMV5-56SLD,AMV5-63SLD, AMV5-72SLD. Fig 4.4.3 Dimension of air return...
- Page 18 Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit 1000 AMV5-63SLD 1300 AMV5-72SLD 1185 4.4.3 Installation of Air-return Duct Square flange is defaulted to be fitted on the back before ex-factory. Air-return cover is on the bottom, as shown in Fig.4.4.4. Fig 4.4.4 If air return from the bottom is needed, switch the positions of square flange and air-return cover.
-
Page 19: Installation Of Wired Controller
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Fig.4.4.6 Fig.4.4.7 4.5 Installation of Wired Controller Please refer to User Manual of Wired Controller for the installation details. Note: When installation is finished, the unit must be tested and debugged before operation. Please refer to Instruction Manual of ODU for auto addressing and debugging details. -
Page 20: Power Cord Connection
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit so that the single-core wire can be exposed. 2) Use a screwdriver to remove the terminal screw on the terminal board. 3) Use a plier to bend the end of single branch line until it forms a circle that has a similar size with the screw. -
Page 21: Connection Of Communication Line Of Idu And Odu
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit 3) Connect the power cord to the L, N terminals and the grounding screw. 4) Fasten the power cord with a wire clamp. For air conditioner that uses 3-phase power 1) Lead the wire across the rubber ring. -
Page 22: Instructions On Connecting Wired Controller And Idu Network
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Fig 5.4.1 Fig 5.4.2 2) Fig.5.4.2 shows the installation of remote controller. 3) Wired controller and receiving light board can be installed at the same time. When operating through a remote controller, both wired controller and the receiving light board can receive the signals, as shown in Fig.5.4.3. - Page 23 Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit Fig 5.5...
-
Page 24: General Maintenance
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit 6 General Maintenance Warning! ①Before the cleaning, turn unit off and disconnect power supply. Otherwise, it may result in electric shock or personal injury. ②When cleaning the air conditioner, please use stable standing platform. ③Do not clean the unit using hot water of over 45 to prevent the unit from losing color or deforming. -
Page 25: Troubleshooting
Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit 8 Troubleshooting If your air conditioner is not working well, please check the following table first before asking for service: Phenomenon Troubleshooting Power supply is not connected. Circuit breaker tripping caused by leakage of electricity. The unit can’t start Input voltage is too low.
