OTHER RECORDING FUNCTIONS
OTHER RECORDING FUNCTIONS
Recording a Single Image (1-Image)
With the 1-Image Mode, a single snapshot is recorded when
you press the shutter release button.
1.
Align the drive mode dial with
2.
Align the power/function switch with
3.
Press the shutter release button to record the
image.
IMPORTANT!
• In any of the following cases, the message "One mo-
ment please..." appears on the display after you
record each image as it is saved to the memory card.
— When you are recording TIFF (uncompressed) im-
ages (page 95)
— When you are recording a movie or panorama
(pages 91, 93)
— When you are recording using certain Best Shot
scene setups (page 76)
— When the
low battery indicator is on the dis-
play while you are using a CompactFlash card
(page 33)
— When the
low battery indicator is on the dis-
play while you are using an IBM Microdrive (page
33).
Previewing the Last Image Recorded
Normally, you need to enter the PLAY mode (page 109) to
display an image on the camera's monitor screen. The fol-
lowing procedure lets you view the image you just recorded
without leaving the REC mode.
(1-Image).
Press PREVIEW to display the last image re-
.
corded.
• You can also use PREVIEW in the Movie Mode to view the
last frame you recorded.
• Pressing PREVIEW again returns to the REC mode
screen.
• Turning off the camera or switching to the PLAY mode
causes the preview image memory to be cleared. This
means nothing appears on the monitor screen if you press
PREVIEW immediately after you turn the camera on or re-
enter the REC mode.
54
