PROFLAME WALL MOUNT TRANSMITTER
ADVANCED REMOTE CONTROL SYSTEM
w
w
w
.
s
i
t
g
r
o
u
p
.
i
t

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Proflame and is the answer not in the manual?

Questions and answers

Related Manuals for SIT Group Proflame

Summary of Contents for SIT Group Proflame

  • Page 1 PROFLAME WALL MOUNT TRANSMITTER ADVANCED REMOTE CONTROL SYSTEM...
  • Page 2 IMPORTANT The Proflame transmitter is an integrated part of the Proflame System, which consists of these elements: • Proflame transmitter, to be used in conjunction with Integrated Fireplaces Control (Proflame IFC) The Proflame transmitter provides for controlling the following hearth appliance functions: 1.

  • Page 3: Technical Data

    Is Reduced WITh loW bATTeRy level. WAll mouNTING The Proflame remote control is supplied with an adapter for wall mounting. Install the controller 1.5 m (5 ft) above floor level, well away from heat sources, kitchens, doors or windows.

  • Page 4: Operating Procedure

    opeRATING pRoceduRe Initializing the System for the first time 1. Power the receiver (install receiver batteries if necessary). 2. Turn the receiver control on, or verify the receiver control is on. 3. Activate the programming mode on the receiver according to the receiver instructions (NOTE: The receiver may be independent or integrated to the IFC (Ignitions and Flame Control) hearth appliance control module.

  • Page 5: Room Temperature

    Remote‑Flame Control The Proflame has six (6) flame levels. With the system on, and the flame level at the maximum in the appliance, pressing the Down Arrow Key once will reduce the flame height by one step until the flame is turned off.
  • Page 6 If the appliance is equipped with a hot air circulating fan, the speed of the fan can be controlled by the Proflame system. The fan speed can be adjusted through six (6) speeds. To activate this function use the Mode Key (fig.1) to index to the fan control icon (Fig. 13). Use the Up/Down Arrow Keys (Fig.1) to turn on, off or adjust the fan speed (fig.
  • Page 7 Pressing the Up Arrow Key will activate the Continous Pilot Ignition mode (CPI). Pressing the Down Arrow Key will return to IPI. A single “beep” will confirm the reception of the command. NOTE: this function is available only with Proflame IFC. NOTE: If the system is equipped with a CPI/IPI toggle switch: •...
  • Page 8 The intensity of the output can be adjusted through six (6) levels. Use the Up/Down Arrow Keys (Fig.1) adjust the output level (fig. 16). A single “beep” will confirm reception of the command. Note. This function is available only with the Proflame IFC. Fig. 19 Fig.

  • Page 9: Low Battery Power Detection

    Key locK This function will lock the keys to avoid unsupervised operation. To activate this function, press the MODE and UP Keys at the same time (fig. 23). To de-activate this function, press the MODE and UP Keys at the same time. Fig.
  • Page 10 (for 315mhz version only) The “proflame Wall mount transmitter” complies with the following requirements: - fcc (federal communications commission) part 15 operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 11: Dimensional Drawings

    Ø3 Ø3 Dimensions in millimeters. PROFLAME transmitter dimensional drawing Fig. 24:...
  • Page 12 SIT La Precisa S.p.A. Viale dell’Industria 31-33 35129 PADOVA - ITALY Tel. +39/049/829.31.11, Fax +39/049/807.00.93 www.sitgroup.it - e-mail: mkt@sitgroup.it...
