OVER THE DESK ADJUSTABLE TABLE
Model: PLUS
TLL-PLUS- *
Assembly and instructions
Please keep hands away from the support bars. They move during height adjustment and
1-
may cause injuries.
To avoid damage, please ensure all objects on the workstation are secure and not
2-
exceeding the edges.
Adhesive clips help to keep cables organized. Please leave enough length of the cables to
3-
allow for height adjustment.
To remove your computer and accessories, please first raise the workstation to the highest
4-
position in order to avoid any damage or injury.
If the workstation needs to be moved, please ask another person for assistance.
5-
Fax: 1-800-835-4403
Please read all instructions carefully before using
this product. Keep this manual for future reference.
The specifications of this product may vary slightly
from the illustrations and are subject to change
without notice.
Caution!
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLUS TLL-PLUS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Outwater PLUS TLL-PLUS Series

  • Page 1 ARCHITECTURAL PRODUCTS by OUTWATER 24 River Road, P.O. Box 500, Bogota, NJ 07603-0500 Phone: 1-800-835-4400 • Fax: 1-800-835-4403 www.outwater.com OVER THE DESK ADJUSTABLE TABLE Model: PLUS TLL-PLUS- * Assembly and instructions Please read all instructions carefully before using this product. Keep this manual for future reference.
  • Page 2 A+B=3~15k g ° ‹ ° ‹ Part List Note: The drawings above are for reference only and may vary slightly from the actual product. If you are missing any component or have any questions, please contact Architectural Products by Outwater.
  • Page 3 Assembly Instructions Step 1 Please Remove packaging and place the product on the table Please ensure that the table you are placing the workstation on is at least the size shown on the technical data page. Step 2 Attach the decorative cover towards the center of the x-shaped support.
  • Page 4 Step 3 Attach the junction plate and keyboard ray using 8 screws. Tighten with a Phillips screwdriver. Step 4 Hang the junction plate on the knobs shown assembled and then tighten the knob on both sides. Tighten...
  • Page 5 Step 5 Press the handle grips both sides simultaneously and adjust the workstation to the desired height. Please do not put hands near the support bars to avoid risk of injury during height adjustment.
  • Page 6 Step 6 Place desired objects onto the workstation. Please ensure all objects on the workstation are secure and not exceeding the edges. Step 7 The wire management clips are self-adhesive to stick to the underside of the workstation. Please ensure that the cables will not hinder the correct functioning of the table.
