User Manual
Version 1, May 2017
Dear user
Thank you for using CG Wizard, this tool has been made to ease the process of balancing a plane.
In this manual there is a description of the different components of the CG Wizard and a quick start
procedure as well.
Should you have any questions regarding the use of this tool, you can refer to the video tagged by the
following QR Code or contact us by email to
support@digitech.nl
This tool has a laser pointer included, please do no stare into beam.
P a g e
1 | 11
Advertisement
Related Manuals for DigiTech CG Wizard
Summary of Contents for DigiTech CG Wizard
- Page 1 Dear user Thank you for using CG Wizard, this tool has been made to ease the process of balancing a plane. In this manual there is a description of the different components of the CG Wizard and a quick start procedure as well.
-
Page 2: Components Descriptions
Central Box This is the core of CG Wizard, it has 4 connectors, 3 for the sensors and one for the power bank. The small power connector is fragile, please check orientation before forcing to plug it in the wrong direction, it may be damaged otherwise. -
Page 3: Center Of Gravity
Center of gravity Step 2: Put the components of the CG Wizard on a flat and leveled surface. Be sure to plug the right sensor on the right port of the central box. Each sensor is factory calibrated to be plugged on a specific port. - Page 4 Step 3: Put the plane on the sensors and proceed to the following measurements Step 3.a: Draw a line between the rear ends of the main sensors. Measure the distance between the center of this line and the rear end of the front sensor. This distance is the sensors spacing.
-
Page 5: Target Distance
Step 4: Using the laser pointer, aim to the line previously drawn is step 1. Step 4.a: Measure the perpendicular distance between the reference notch on the Central Box and the line drawn on step 3.a This is the target distance Target distance P a g e 5 | 11... - Page 6 Step 5: Now just add or remove weight on the plane in order to match the Balance point shown in the app with the target distance. P a g e 6 | 11...
- Page 7 P a g e 7 | 11...
- Page 8 P a g e 8 | 11...
- Page 9 P a g e 9 | 11...
- Page 10 P a g e 10 | 11...
- Page 11 P a g e 11 | 11...
