Slimline Wall Mounted Tablet Enclosure
Range Instructions
016_08_000 / 016_10_000 / 016_12_000
Items Supplied
A
A
A - Rear Enclosure
B - Tablet Tray Assembly
Additional Tools Required
E - Screwdriver (Or Power Drill - Surface Dependent)
F - Wood/Masonry Screw x 7 (6mm max. Diameter)
+44 (0) 1202 892 863 |
Unit B8, Arena Business Centre, Nimrod Way, Wimborne, Dorset. BH21 7UH.
E
A
1-888-858-9778 | sales@imageholders.com
Slimline Glass Mount Instructional Video:
https://youtu.be/49ZwM0YzJyU
B
B
D
D
C - Bezel and Cassette Assembly
D - Enclosure Key
Note: B & C may vary based on your chosen Tablet
G
C
H
D
G - Spirit Level
H - Pencil
C
C
F
B
