- Page 1 DOCKMATE, single-handed wireless remote control over your boat. Installation manual...
- Page 2 Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu – www.dockmate.eu – info@ppa-electronics.com – www.ppa-electronics.com...
-
Page 3: Safety Precautions
The Dockmate should be installed by a trained and qualified engineer only. FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Preparing The Transmitter
If you’re unable to turn on the transmitter and it won’t charge either, please contact your Dockmate dealer. Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu... - Page 5 The transmitter lost also beeps. Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu...
- Page 6 2. Receiver rev. G overview Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu – www.dockmate.eu –...
-
Page 7: Installing The Modules
4. Connecting and installing the antenna To connect the antenna to your Dockmate, connect the antenna directly or with the optional extension cable to the SMA connector on the front of the Dockmate Receiver. - Page 8 It must be connected to a switch that is marked ‘Dockmate’, and/or to the starting key. On the picture the power connector inside the Dockmate is shown. The wires are connected to the connector on the front panel shown below.
-
Page 9: Pairing The Transmitter And Receiver
Switch off the power of the transmitter and the receiver, then switch on again. Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu... -
Page 10: Programming / Settings
MINIPROGRAMMER and LIVEVIEW CABLE + DOCKCONTROL software installed on the LAPTOP. Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu... - Page 11 8. Connecting the horn module The first step of connecting the Dockmate to the boat is by connecting the horn module. Please note that when depressing the ‘Horn’-button on the single and twin transmitter, there will be a delay time of about 0,6 seconds.
- Page 12 “take command” button. Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu...
- Page 13 Note : White and yellow wires must be left unconnected. Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu...
- Page 14 In DockControl please select ‘Standard relay on-off type’. Default time - delay before switching to other direction is 0.8s. Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu...
-
Page 15: Engine Modules
There are no generic engine modules. Installation drawings and procedure is delivered in a separate manual for specific brand of engine controls Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu... - Page 16 For all analogue engine modules For Speed Ctrl modules only Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu...
- Page 17 At this point your DOCKMATE system is ready to use. From now on you can dock your ship single handed! Dockmate is a registered trademark from PPA-Electronics B.V. Leuvensesteenweg 177 – BE-3191 Boortmeerbeek – Belgium VAT BE 0891.773.260 – Tel. +32 (0)15 43 39 94 – Mob. +32 (0)475 45 37 35 info@dockmate.eu...
