Set Up Manual
Trong™ -
Dual Camera Extendable Mobile DVR
With GPS Tracking and Live Remote Viewing
6000 SERIES
ENGINEERED FOR
VEHICLE SAFETY.
TM

Advertisement

loading
Need help?

Need help?

Do you have a question about the RVS Trong 6000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Safe Fleet RVS Trong 6000 Series

  • Page 1 Set Up Manual Trong™ - Dual Camera Extendable Mobile DVR With GPS Tracking and Live Remote Viewing 6000 SERIES ENGINEERED FOR VEHICLE SAFETY.
  • Page 2 This manual explains how to set up your Trong with our free Trong 2. The next step is connecting your phone to the Trong device via WiFi. Mobile App. This app allows you to access your Trong recording device via a WiFi signal provided by the device. 1) Open your phone WiFi settings in your phone.
  • Page 3 3. Format your SD cards. Navigate to "Settings" in the app. Next 4. If you are using 1 SD Card, select "Format SD 1". click on "Control." REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
  • Page 4 5. Once SD Card 1 is selected, click "OK" to confirm formatting. 6. To connect to your Trong Device remotely using a 3G/4G SIM Card, you'll need to set up your Device via the Trong App. If you have two SD cards, repeat for SD Card 2. 1) Go to Settings Tab.
  • Page 5 7. In 3G/4G Network menu, select "APN". 8. Now that your APN is set, you'll have to make sure that you're connecting to the correct server, the RVS server. An APN is a code that identifies the Sim Card network. This is Return to "Network Settings"...
  • Page 6 9. To set an Alarm/Trigger, navigate to Alarm Settings from Settings Tab. 10. There are three alarm types: • Speed - Alarm that is triggered when the speed of the vehicle exceeds the set limit. Default Speed source is GPS Antenna. •...
  • Page 7 11. Speed Menu Speed Source: How your Trong detects speed. Leave "GPS" selected as default. Speed Unit: Select MPH or KMH GPS Mode: Default setting and should not be changed Alarm Type: Parking/Low Speed/High Speed Open: Activates Alarm Limit: An alarm is triggered when this speed is exceeded Hold: Length in seconds sensor must be triggered before an event occurs Delay: How long the trigger period is registered as one trigger event REC Upload: Send footage to server...
  • Page 8 12. I/O Alarm I/0-1: Choose which I/O sensor to use for setup Alarm Type: Urgent/Front Door/Back Door/etc Trigger Mode: Alarm Urgency (Voltage Level) Hold: Length in seconds sensor must be triggered it is indicated as an event Delay: Length in seconds trigger period is registered as one trigger event Photograph: (Checkbox) Determines which cameras take a snapshot upon triggering (if any) Record Locked: (Checkbox) Protects cameras footage upon triggering...
  • Page 9 13. G-Sensor Choose which axis that sensor should read to detect movement/ transform coordinates. X: Horizontal / Y: Vertical / Z: Forward/Backward Choose the limit (sensitivity) for which the event is triggered via number value. The higher the value, the higher the sensitivity. Experiment for desired sensitivity, as this setting is your preference.
  • Page 10 14. Trong FAQ 2) Select Recording Settings 1. My camera looks backwards, how do I reverse the image? The "Mirror" Function allows you to flip the camera image vertically and horizontally. 1) Go To System Settings REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
  • Page 11 3) Select MainbitStream 4) Select which Channel/Camera you'd like to adjust on the top line. REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
  • Page 12 15. Trong FAQ (Q 2) Select "Mirror". Q: I plugged In my 2 additional Cameras and they are showing Adjust as desired. up black. A: In the Record Parameters page, select Camera Type, and select the correct format for the cameras you are adding. If you are using AHD cameras, please select 2*1080P &...
  • Page 13 16. Trong FAQ (Q 3) NOTES Q: Camera 1 & 2 are showing black. A: Under "Record parameters", please select TV System and select NTSC. Then please Reboot/Restart the Trong REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
  • Page 14 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 ENGINEERED FOR VEHICLE SAFETY.
