Spiker Scangauge Installation Instructions Manual

Spiker Scangauge Installation Instructions Manual

Mounting bracket for '96-'02 4runner & '96-'00 tacoma

Advertisement

'96-'02 4Runner & '96-'00 Tacoma
Scangauge Mounting Bracket
Installation Instructions
NOTE: The latest version of the installation manual is on our website. Please download it and check its release date
against the date of this manual (highlighted in yellow below). Follow the instructions of the latest release date. Link to
manual -
https://spikerengineering.com/installation
Thank you for purchasing the Spiker Engineering Scangauge Mounting Bracket. Please follow this manual carefully to
ensure a quality installation and many years of reliable service.
It is the customer's responsibility to understand all of the work involved in the installation process, and to ensure
compatibility with their vehicle. No warranty is implied for the installation, and we will not be responsible for damage to
your truck, engine, or other parts, labor, personal injury, or any other damage or injury resulting from use of these
products.
Customer understands that all parts are aftermarket parts and have no OEM specifications.
If you have any questions or concerns at any point of the installation process, please contact us at
service@spikerengineering.com
before proceeding, we'll be happy to help.
Rev 7/4/2020
This manual is property of Spiker Engineering. Any unauthorized duplication or use without written permission from Spiker
Engineering violates Copyright laws.
Copyright © 2020 Spiker Engineering. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scangauge and is the answer not in the manual?

Questions and answers

Summary of Contents for Spiker Scangauge

  • Page 1 - https://spikerengineering.com/installation Thank you for purchasing the Spiker Engineering Scangauge Mounting Bracket. Please follow this manual carefully to ensure a quality installation and many years of reliable service. It is the customer’s responsibility to understand all of the work involved in the installation process, and to ensure compatibility with their vehicle.
  • Page 2 (5) Enjoy a beverage of your choice to celebrate! The figure below provides an overall view of the components involved in the installation, please refer to it as you go through the steps in the following sections. Copyright © 2020 Spiker Engineering. All Rights Reserved.
  • Page 3 To avoid stripping the screw head, use a cordless impact driver with a No. 2 JIS (not Philips) bit, such as the Motion Pro JIS Crosshead Hex Drive Bit (No. 2) or the Makita Impact Bit: Copyright © 2020 Spiker Engineering. All Rights Reserved.
  • Page 4 Place the adapter plate in front of the mounting bracket, and line up the holes, making sure that the cutout in the adapter plate is on the right, as shown below. Secure the two brackets together with the bolt and nut provided. Don’t fully tighten the nut at this point, to allow adjustments. Copyright © 2020 Spiker Engineering. All Rights Reserved.
  • Page 5 Scangauge against the Dual Lock strips on the adapter plate firmly to engage the adhesive, and hold tight for about 30 seconds. The Dual Lock strips should be sufficient to hold the Scangauge, however you can add a couple of zip ties to hold the Scangauge to the bracket even more securely.
  • Page 6 Copyright © 2020 Spiker Engineering. All Rights Reserved.
