- Page 1 Installations Manual Passive Ventilation Counter Current Heat Exchanger • GE Energy 1 • GE Energy 2 • GE Energy 3 Version 1.02 - 0110...
-
Page 2: Table Of Contents
Table of contents GES Energy 1 - Installation..........4 GE Energy 1 - Installation ..........4 Energy 2 - Installation ..........5 Energy 3- Installation ...........5 Duct connection ............6 Duct system ..............6 Condensate drain ............7 Insulation of ducts in cold loft spaces .......7 Insulation of ducts in heated spaces......8... - Page 3 GENVEX A/S can season make sure that the drain is properly filled not be made responsible for any additional damages, with water. which have nothing to do with the GENVEX unit. IMPORTANT IMPORTANT IMPORTANT IMPORTANT...
-
Page 4: Ges Energy 1 - Installation
Installation GE Energy 1 GE Energy 1 - Installation The GE Energy 1 is available in a right-hand version (as Dimensions in mm shown). For a mirror image unit, the front and rear panels may be removed, the back panel mounted on the front and the unit rotated 180°. -
Page 5: Energy 2 - Installation
Installation GE Energy 3 GE Energy 3 - Installation The GE Energy 3 is supplied in a right-hand version (as Dimensions in mm shown) or left-hand version (mirror image), in which the fresh air exchanges places with the extract air and the supply air with the escaping air. -
Page 6: Duct Connection
Installation Duct connection All duct connections display a yellow sticker indicating the Friskluft type of ventilation channel to be connected. Incomming Air Frischluft Connect the supply air: Duct system from the unit to the supply outlet in the living Afkast Exhaust Air room. -
Page 7: Condensate Drain
Installation GE Energy 1 - 3 Condensate drain The units produce up to 10 litres of condensate per day. It is therefore important that the condensate drain is correctly Fresh Air Extract Air executed and that the unit has a slight fall towards the condensate drain. -
Page 8: Insulation Of Ducts In Heated Spaces
Installation Insulation of ducts in heated spaces Supply and extract ducts: In warm loft spaces the supply and extract channels must be insulated with 50 mm insulation. Supply and extract ducts led through heated spaces in dwellings do not require insulation. If the supply air duct has cooling, bypass or earth heat exchanger installed it must be insulated. -
Page 9: Electrical Installation
To start up the unit before adjustment, do as follows: Before starting up the unit: 1: Check that the Genvex unit is correctly mounted and that all ducts are insulated as required. 2: Check that hatches can be opened so that service and maintenance on the unit can be carried out. -
Page 10: Optimum Initial Adjustment Of Plant
10-15 seconds until the Genvex logo starts flashing again and the equipment is back in normal operation. - Page 11 Til indvendig aflłb Service If you are unable to maintain your unit yourself, you can sign a service agreement with the Genvex service department. If any faults arise in the unit, contact the Genvex service department.
-
Page 12: Fault Finding
Fault finding Fault finding Unit has stopped: The display shows Optima 250 DESIGN: No light in any of the lamps on the control panel, even though both buttons are pressed. Data error: Error: - No communication between the display and controller. - Fuse on electric panel has blown, no power to unit - Cable between display and circuit board to long. -
Page 13: Electric Diagram Ec - Engine
Electrical Diagram... -
Page 14: Electric Diagram Optima 100
Electric Diagram Optima 100 Sensor Heatrelay Sensor defrost... -
Page 15: Eu-Declaration Of Conformity
Installation EU-Declaration of conformity... - Page 16 Tel.: + 385/ (0) 1/ 65 45 407 Fax: + 385/ (0) 1/ 65 45 409 E-Mail: pichler@zg.hnet.hr Portugal Iberterm PT-4475-493 Nogueira Maia Tel: +351 229 065 123/4 Fax: +351 229 065 125 E-Mail: paulo.neto@iberterm.com Web: www.iberterm.com Published by Genvex A/S, Sverigesvej 6, DK-6100 Haderslev www.genvex.dk...
