- Page 1 ISSUE B 11/07/11 35 Fernleigh Road London N21 3AN +44 (0)208 882 0100 +44 (0)208 882 9326 e. mail dmx@xtba.co.uk www.xtba.co.uk. XTBA SMART MERGE4:2 Manual Page 1 of 4 Product #02603 - Issue B 11/07/2011 © XTBA 1986 – 2012...
- Page 2 OPERATION XTBA Smart Merge will merge up to four DMX512 inputs to two DMX512 outputs. In addition the input DMX on each input channel may be movLED relative to the output DMX via the input BCD switches. Any input channels that are movLED beyond the 512 channel limit will be outputtLED via output two.
- Page 3 19” RACK MOUNTING The XTBA Smart Merge 4:2 is provided with a pair of ‘ears’ for fitting into a 19” rack frame. The ears are fitted to the unit by removing the two screws on either side at the front of the unit.
- Page 4 Using the product out of these specifications will remove all responsibility from the supplier. CE Declaration of conformity XTBA declares that the following equipment meets the requirements of the EMC Directive 89/366/EEC. WEE/FC2753ZS XTBA SMART MERGE4:2 Manual Page 4 of 4 Product #02603 - Issue B 11/07/2011 ©...
