- Page 1 VARIABLE SPEED JIG SAW PAINT MIXER PAINT MIXER Part No. 6460200 MODEL No. CON200 Part No. 6462031 OPERATING & MAINTENANCE INSTRUCTIONS 1107...
-
Page 2: Specifications
) ........99.3dB (A) Vibration ............ <2.5 m/s Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. -
Page 3: General Safety Precautions
GENERAL SAFETY PRECAUTIONS WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. -
Page 4: Declaration Of Conformity
Avoid dangerous environments. ADDITIONAL PRECAUTIONS FOR PAINT MIXERS NEVER use third party mixing attachments. Replacement parts can be obtained from you clarke dealer. Additionally, please keep these instructions in a safe place for future reference. DECLARATION OF CONFORMITY... -
Page 5: Electrical Connections
Should you wish to replace a detachable fuse carrier, ensure that the correct replacement is used (as indicated by marking or colour code). Replacement fuse covers can be obtained from your local Clarke dealer or most electrical stockists. FUSE RATING The fuse in the plug must be replaced with one of the same rating (13 amps) and this replacement must be ASTA approved to BS1362. -
Page 6: Parts Identification
PARTS IDENTIFICATION 1. Carbon brush cap 6. Mains lead 2. Torque setting selector 7. Varible speed dial 3. Tool holder 8. Mixing blade 4. Safety Interlock 9. Spare carbon brushes 5. Trigger switch 10. Spanners... -
Page 7: Before Use
BEFORE USE Check the parts for damage before assembly, if any parts are damaged return the unit to your Clarke dealer. FITTING THE MIXING BLADE WARNING! Before removing, or installing the mixing blade, make sure that the mains plug has been removed from the mains supply. -
Page 8: Torque Setting
OPERATING TORQUE SETTING Torque setting selector Move the torque setting selector to select either setting 1(low torque) or 2 (high torque). VARIABLE SPEED Variable speed The variable speed selector is used to selector control the speed of the paint mixer. •... -
Page 9: Maintenance
• After use, clean the mixing blade and allow to dry. • Keep the unit clean and free from oil and grease. • Refer to your CLARKE dealer if internal maintenance is required. MAINTAINANCE With the exception of changing the carbon brushes, there are no other user servicable parts on this paint mixer. -
Page 10: Parts Diagram
PARTS DIAGRAM... -
Page 11: Parts List
PARTS & SERVICE For Spare Parts and Service, please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 or e-mail as follows: PARTS: parts@clarkeinternational.com...
