CEMENT MIXER
MODEL NO: CCM110
PART NO: 3400855
OPERATION & MAINTENANCE
INSTRUCTIONS
GC01/16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCM110 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke CCM110

  • Page 1 CEMENT MIXER MODEL NO: CCM110 PART NO: 3400855 OPERATION & MAINTENANCE INSTRUCTIONS GC01/16...
  • Page 2: Specification

    INTRODUCTION Thank you for purchasing this CLARKE Cement Mixer. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3: General Safety Precautions

    GENERAL SAFETY PRECAUTIONS 1. Always keep the work area clean and well lit. Floors should always be kept clear. Cluttered or dark areas invite accidents. 2. Always keep children and bystanders away while operating a power tool. Distractions can cause loss of control. 3.
  • Page 4: Safety Symbols

    18. Never put any tools or other objects in or around the drum while it is rotating. 19. Never wear jewellery or loose clothing that could be snagged by any part of the rotating drum. 20. Never load the drum when the machine is switched off. Always switch on and ensure the drum is rotating before loading.
  • Page 5: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS1363 plug, or a suitably fused isolator switch. If the plug has to be changed because it is not suitable for your socket or because of damage, it must be removed and a replacement fitted, following the wiring instructions shown below.
  • Page 6 Should any component be found to be damaged or missing, please contact your CLARKE dealer immediately. Check the components against the following list. 1 x Tilt Handwheel...
  • Page 7 ASSEMBLY 1. Bolt the main frame to the axle frame using M8 x 65mm bolts & nuts supplied. 2. Bolt the support stand to the main frame using M8 x 65mm bolts and nuts. 3. Slide the flat washers onto the axles, followed by a wheel and a second flat washer.
  • Page 8 7. Fit the angle adjusting plate to the bearing housing opposite the drive spindle end. Slide it over the cradle spindle and bolt it to the bearing housing with two M8 x 25mm bolts. 8. Insert the return spring into the sleeve on the tilt handwheel and slide the handwheel onto the cradle spindle.
  • Page 9 11. With the drive assembly in position, remove the bolts, nuts and washers securing the motor cover to the backing plate and lift away the cover. 12. Check that the drive belt can be deflected no more than 1/4 inch and that the belt runs true.
  • Page 10: Operation

    • all 8 holes in the upper drum line up with those in the rubber seal and in the lower drum. • the lower tips of the blades line up with their fixing holes in the bottom of the lower drum. 17.
  • Page 11: Care And Maintenance

    5. When emptying, grip the tilt angle wheel firmly and tilt the wheel to disengage the locking pins. 6. Use the wheel to tip the mixer drum forward. • Only discharge the mixer when a suitable receptacle for the cement mix is in position. •...
  • Page 12 STORAGE The mixer can be better stored with the axle frame and support stand folded away. Remove the axle frame and support stand securing bolts and lower the mixer to the floor with the help of an assistant. Loosely re-fit the bolts and nuts into their respective holes.
  • Page 13: Declaration Of Conformity

    DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 14: Parts Diagram

    PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 15: Parts List

    PARTS LIST DESCRIPTION DESCRIPTION DESCRIPTION Bolt M14 x 25 27 Locknut M8 53 Bolt M8 x 15 Mixer Blade 28 Nut M8 54 Screw M5 x 10 Washer 10 dia 29 Circlip 30 dia 55 Spring Washer M5 Upper Drum 30 Main Frame 56 Nut M5 Washer 24 dia...
