- Page 1 Shopping Cart ASSEMBLY INSTRUCTIONS #612428 Adult assembly required. Approx. assembly time: 25min. Toys not included. Look for video of assembly at littletikes.com/videoinstructions XIM612428 - 10/20...
- Page 2 © Thank you for choosing the Little Tikes Shopping Cart . We strive to provide a durable, easy-to-assemble toy thats made to last, giving your child years of imaginative, engaging fun! Really important information you should know! • Read through all the instructions first.
- Page 3 BEFORE you begin assembly, make sure you have all the parts listed below. Some packages of hardware may have extras pieces. Questions? We’re here to help. Little Tikes customer service team at 1-800-321-0183. Hardware Guide Shown actual size (4) 1" (2,54 cm)
-
Page 4: Let's Get Started
Lets get started! First, line up holes on bottom basket (part D) to the slots on the side of base (part A) . 1" (2,54 cm) Screw cover Second, place (1) 1” ( 2,54 cm) screw inside screw cover (part CC) and secure into place. - Page 5 Two baskets make ONE Place top basket (part C) on bottom basket (part D) Screw in (6) " (1,9 cm) screws into bottom basket (part D) " (1,9 cm) Screw cover Place (1) ” (1,9 cm) screw inside screw cover (part CC) and secure into place.
-
Page 6: Attach The Seat
Attach the seat Attach the seat in two steps. First slide one corner of the seat (part D) into the hole on the side of the top basket (part C) . Second, click in the other side until the seat (part D) is in place. - Page 7 Cap it! Place cap nut (part AA) into cap nut tool. Cap nut Do not hammer on surfaces or items you don’t want to Small cap nut tool break, mar or dent. Really give it a good hit! Insert the axle (part E) into the cap nut tool Axle Hammer the axle into the cap nut.
-
Page 8: Ready To Roll
Ready to roll! Get the wheels on. First, turn the shopping cart on its side. Slide axle (part E) through one wheel (C), add a washer (BB). Repeat steps for second wheel. Washer... - Page 9 Ready to roll!...cont. Flip the shopping cart over. Add one washer (BB) to axle (E) Then add a wheel (C). Finish with a cap nut (AA) Do not hammer on surfaces or items Hammer the cap nut onto axle you don’t want to Repeat steps for second wheel.
-
Page 10: Instructions De Montage
Panier de magasinage INSTRUCTIONS DE MONTAGE mois Montage par un adulte requis. Durée de montage approximative : 25 min. Merci d’avoir choisi l’ensemble Shopping Cartde Little Tikes © . Nous sommes déterminés à fournir un jouet durable et facile à monter, procurant à... -
Page 11: Service Consommateurs
à compter de sa date d’achat (le reçu d’achat daté est exigé comme preuve d’achat). Au titre de la présente garantie, la seule responsabilité de The Little Tikes Company et le seul recours se limitent Procédez de la même façon de l’autre côté. -
Page 12: Instrucciones De Montaje
El montaje debe realizarlo un adulto. Tiempo aproximado de montaje: 25 min. © Gracias por elegir Little Tikes TotSports™ Juego de básquetbol. Nos esforzamos por crear juguetes perdurables, fáciles de ensamblar y creados para durar, que brindan a sus niños años de diversión fascinante y ocurrente. -
Page 13: Servicio Al Cliente
Impreso en E.U.A. su lugar. © The Little Tikes Company, una compañía de MGA Entertainment. LITTLE TIKES® es una marca registrada de MINIMUM SIZE allowed is .2” high Little Tikes en EE.UU. y otros países. Todos los logotipos, nombres, personajes, representaciones, imágenes, Repita el paso del otro lado. -
Page 16: Consumer Service
LIMITED WARRANTY The Little Tikes Company makes fun, high quality toys. We warrant to the original purchaser that this product is free of defects in materials or workmanship for one year * from the date of purchase (dated sales receipt is required for proof of purchase).
