Summary of Contents for Baruffaldi TOEM 120
- Page 1 Pagina N°. Page Nr. Edizione S.p.A 11-93 Edition...
- Page 2 Pagina N°. Page Nr. ASSEMBLY DRAWING Edizione S.p.A (section view) 11-93 Edition...
- Page 3 ( __ __ ) for TOEM 200 - 250 for TOEM 707a 120 - 160...
-
Page 4: Turret Disassembly
Pagina N°. TURRET DISASSEMBLY Page Nr. (Related to the toolholders Edizione S.p.A 11-93 rotation) Edition - Set out the turret in open position (unlocked) - Remove the screws 714 and 715 - Remove all the support ( S ) complete of gear 712, (to facilitate the removing of this last, hit the ends ( E ) with a plastic hammer). - Page 5 Slot ( A ) for Extremity (E) locking pino clutch (708) (on line with hole F) extremity (E) gear (712) on line Turret (mm) (mm) size TOEM 120 TOEM 160 TOEM 200 TOEM 250 Surfaces on contact GROUP ( I )
- Page 6 S n°4 Diameter Diameter Turret R (mm) S (mm) size 8,25 TOEM 120 8,25 TOEM 160 8,25 TOEM 200 8,25 TOEM 250 Whenever the turret is disassembled, check the state of the following elements which will have to be replaced in...
- Page 7 Assemble the parts as shown, then check that the value of U is between the ranges in the table below. If it is not then grind a new distance piece 025 to it so that U falls within the ranges specified in the table. Turret Dimension size U(mm) TOEM 120 TOEM 160 TOEM 200 TOEM 250...
-
Page 8: Page Nr
Pagina N°. HINTS FOR Page Nr. REASSEMBLE Edizione S.p.A 11-93 Edition DURING COMPLETE REASSEMBLE - Insert the keys 309 into their corresponding key-ways (with identical marks) keeping the threaded holes turned towards the ring nut 020 and in contact with the bottoms of the key-ways. - Check that pinion 008 has a good sliding fit. -
Page 9: Toem 120 Toem 160 Toem 200 Toem 250
The lubricant must be renewed only after eventual complete dismantling of the turret. The lubricant, with viscosity 80 SW 90, must be compatible with rubber & teflon. The following table indicates the quantities to be used. Turret size Quantity of oil TOEM 120 0,500 TOEM 160 0,700 TOEM 200... - Page 10 Adjust the air gap (0,2 - 0,3 mm to be checked in a vertical position and acting on the distance pieces 090). Reassemble the whole by following the above sequence in reverse. TOEM 120 - 160 - 200 - 250...
- Page 11 SUBSTITUTION AND Pagina N°. Page Nr. ADJUSTEMENT OF THE Edizione S.p.A 11-93 ANGULAR ENCODER Edition Remove the rear cover 011, disconnect the encoder leads from the terminal block 310, remove the stirrups 067 and extract the encoder. Remove the driving hub 035 and mount it on the new encoder. Remount the encoder following the above instructions in reverse and connect it to the terminal blocks.
- Page 12 "red" indicator on the back part of the proximity switch should light up. Replace the rear cover and the top cover. 300 a Luminous indicator Turret size (mm) TOEM 120 18,3 TOEM 160 18,3 TOEM 200 18,3 TOEM 250...
- Page 13 Replace the wire clip, the rear cover and the top cover. Hole ( n ) Luminous indicator Turret size Indicative value of Z (mm) Closing sector ( i ) TOEM 120 60,7 TOEM 160 59,7 TOEM 200 60,7 TOEM 250...
- Page 14 Screw on the wire clip, reconnect the leads to the terminal block (care the phases of the motor leads), replace top and rear covers. Turret size Size of spanner CH (mm) TOEM 120 TOEM 160 TOEM 200 TOEM 250...
- Page 15 Pagina N°. RECCOMENDED Page Nr. SPARE PARTS Edizione S.p.A 11-93 Edition Pads (2 off) Fluid coolant valvle Motor unit Encoder unit Brake magnet Electromagnet Pre-indexing proximity switch Wiping seal Locking proximity switch O - ring O - ring O - ring O - ring O - ring O - ring...
- Page 16 Page Nr. ROTATING TOOLHOLDERS Edizione S.p.A 11-93 POWER TAKE-OFF Edition TECHNICAL DATA TOEM 120 TOEM 160 Max. torque at the take power Max. power g/min Max. speed at the take power 6000 6000 Ratio (RPM motor / RPM take power)
- Page 17 Pagina N°. TABLE OF DATA Page Nr. TURRETS Edizione S.p.A 11-93 Edition TOEM 160 TURRET SIZE TOEM 120 Code number of transmission TOEM 120/../0 TOEM 160/../0 TOEM 120/../1 TOEM 160/../2 ratio TOEM 160/../1 Moment of inertia of trans- 0,65 0,50...
- Page 18 TOEM 200 7 0 0 TOEM 160 5 0 0 4 0 0 3 0 0 TOEM 120 2 0 0 1 0 0 a ( m m ) As a function of the As a function of the lifting axial force F3...
- Page 19 Pagina N°. Page Nr. PROBLEMS & REMEDIES Edizione S.p.A 11-93 Edition PROBLEMS CAUSE REMEDY Turret does not start No power at motor Get power to the motor Motor defective Substitute the motor unit (see page 26 ) Heat sensor in operation See next point Turret does not complete its Number of movement / hour above...
- Page 20 Pagina N°. Page Nr. PROBLEMS & REMEDIES Edizione S.p.A 11-93 Edition PROBLEMS CAUSE REMEDY Delay in switching off the motor and Overhaul the control apparatus Turret does not stay locked in the braking Brake defective Substitute the brake magnet (see page 26) Brake wear excessive Readjust the air gap in the brake (see page 26)
- Page 21 Pagina N°. PROBLEMS & REMEDIES Page Nr. for the rotating toolholder Edizione S.p.A 11-93 Edition PROBLEMS CAUSE REMEDY Rotating toolholder failure Restore the toolholder integrity or The rotating toolholder does not replace it with a new one rotate Supplementary motor failure Replace the supplementary motor (see page 20) The input to the supplementary...
