Chauvin Arnoux AmpFlex A100 Manual

Flexible current sensor
Hide thumbs Also See for AmpFlex A100:
Table of Contents

Advertisement

Quick Links

AmpFlex
A100
®
Mobile: +62 816 1740 8925
Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia
Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia
Fax: 021-8690 6771
Phone: 021-8690 6777 (Hunting)

Advertisement

Table of Contents
loading

Related Manuals for Chauvin Arnoux AmpFlex A100

Summary of Contents for Chauvin Arnoux AmpFlex A100

  • Page 1 AmpFlex A100 ® Mobile: +62 816 1740 8925 Office: Jl. Radin Inten II No. 62 Duren Sawit, Jakarta 13440 - Indonesia Workshop: Jl. Pahlawan Revolusi No. 22B, Jakarta 13430 - Indonesia Fax: 021-8690 6771 Phone: 021-8690 6777 (Hunting)
  • Page 2 Thank you for purchasing an AmpFlex A100 flexible current sensor. ® For best results from your instrument: „ read these operating instructions carefully, „ comply with the precautions for use. WARNING, risk of DANGER! The operator must refer to these instructions whenever this danger symbol appears.

  • Page 3: Table Of Contents

    PRECAUTIONS FOR USE „ Comply with the rated maximum voltage and current and the measurement category. „ Never exceed the protection limits stated in the specifications. „ Comply with the conditions of use, that is to say temperature, humidity, altitude, degree of pollution and location of use.

  • Page 4: Presentation

    1. PRESENTATION 1.1. STANDARD MODELS IN A A100 SERIES A100 Series AmpFlex® sensors make up a range of nine standard models which enable the measurement of alternating current from 0.5 A to 10 kA at industrial frequencies. Each probe is of a flexible air-core type (45 cm, 80 cm or 120 cm) attached by a shielded cable to a small box housing the integrator circuit and a standard 9 V battery.

  • Page 5: Description

    2. DESCRIPTION See illustration on p 50 Air core Lenght 45 cm 80 cm 120 cm Weight < 120 g < 240 g < 360 g Latch device Cable: 2 m lenght Box: dimensions 140 x 64 x 28 mm - weight 200 g Sliding switch with two positions (single range) or three positions (dual range) Green «ON»...

  • Page 6: Specifications

    4. SPECIFICATIONS 4.1. REFERENCE CONDITIONS „ Temperature: +18 ... +28°C „ Relative humidity: 20 ... 75 % HR „ Battery voltage: 9 V ± 0.5 V „ Measurement of sinusoidal alternating current: 10 Hz to 100 Hz „ Continuous magnetic field: Earth’s magnetic field (< 40 A/m) „...

  • Page 7: Power Supply

    4.3. POWER SUPPLY „ 9V alkaline battery (of type 6LF22) „ Normal operational voltage: between 9 V and 7 V „ Battery life: - continuous operation: 150 hours - intermittent use: 10,000 1-minute measurements „ Battery low indicator: green “ON” LED flashes 4.4.

  • Page 8: Compliance With Electrical Standards

    4.5. COMPLIANCE WITH ELECTRICAL STANDARDS 4.5.1 ELECTRICAL SAFETY IN LINE WITH IEC 61010-1 (IEC 61010-031, IEC 61010-2-032) „ Double insulation „ Installation category III „ Operating voltage: 1000 V „ Pollution level 2 4.5.2 ELECTROMAGNETIC COMPATIBILITY „ Emissions and immunity in an industrial environment per IEC 61326-1. - Electrostatic discharge (meets EN 61000-4-2) 8 kV in air - level 3 - class B 4 kV on contact - level 2 - class B...

  • Page 9: Maintenance

    5. MAINTENANCE When performing maintenance, use only the specified replacement parts. The manufacturer cannot be held responsible for any accident occurring subsequent to repair work carried out by parties other than its own after-sales service team or agreed repair personnel. 5.1.
