16-F & 16-Fp
SPACE SAVER
Frozen Fry Dispenser
Equipment Manual
English
P/N 310157 Rev. A
Manufactured By
Automated Equipment LLC
5140 Moundview Drive
Red Wing, MN 55066 U.S.A.
For Warranty Service & Technical Support, call
:
US & Canada support call: 1 (800) 248-2724
International support call: 1 (651) 385-2273
Sales Fax: 1 (651) 385-2166
Service Fax: 1 (651) 385-2172
http://www.autoequipllc.com
Business Hours:
Monday - Friday: 8:00 AM to 5:00 PM CST
(excluding. holidays)
After hours, your call will be handled by a voice mail
paging service. The on call technician will be paged and
will return your call
Table of Contents
Introduction ............................................................................................................................................. 1
Unpacking & Installation ........................................................................................................................ 1
Intended Use ........................................................................................................................................... 1
Equipment Safety .................................................................................................................................... 2
Dispenser Assembly ............................................................................................................................... 5
Operator Panel and Controls ................................................................................................................. 6
Start up and Operation ........................................................................................................................... 7
Daily Closing: Disassembly, Defrost & Cleaning ................................................................................ 8
Temperature Controller Operation and Menu Structure ..................................................................... 9
Error Detection ...................................................................................................................................... 10
Troubleshooting .................................................................................................................................... 11
Part Identification .................................................................................................................................. 12
Refrigeration System ............................................................................................................................ 17
Electrical Diagram ................................................................................................................................. 21
Specifications ........................................................................................................................................ 22
Service Information .............................................................................................................................. 23
Disposal of Equipment ......................................................................................................................... 24
Copyright © 2019
Automated Equipment LLC
All rights reserved.
Published 8/19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AUTOMATED EQUIPMENT RAM 16-F
Summary of Contents for AUTOMATED EQUIPMENT RAM 16-F
-
Page 1: Table Of Contents
Frozen Fry Dispenser Equipment Manual English P/N 310157 Rev. A Manufactured By Automated Equipment LLC 5140 Moundview Drive Red Wing, MN 55066 U.S.A. For Warranty Service & Technical Support, call US & Canada support call: 1 (800) 248-2724 International support call: 1 (651) 385-2273... - Page 2 This manual is copyrighted with all rights reserved. Under the copyright laws, this manual may not be copied, in whole or part, without the written consent of Automated Equipment LLC. Product names mentioned herein are for identification purposes only, and may be trademarks and/or registered trademarks of their respective companies.
-
Page 3: Introduction
If the power cord is damaged, it must be replaced by the manufacturer, or its service agent, or a similarly qualified person in order to avoid a hazard. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 4: Equipment Safety
Children should be supervised to ensure that they do not play with the appliance. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... - Page 5 US and Canada Label is located on the front and applies to the outlet door assembly. CAUTION, MOVING PARTS. HANDS SHOULD NOT BE PLACED NEAR OR BELOW THE OUTLET DOOR. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
- Page 6 Caution: The 16-Fp utilizes R290 (propane) as a refrigerant. Release of refrigerant into the atmosphere is strictly prohibited. Caution: Propane (R290) is highly flammable. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
-
Page 7: Dispenser Assembly
DO NOT force the drum on to the shaft. Rotate the drum in the hopper until the square opening meshes with the drum motor shaft, then slide the hopper assembly backward until it drops into place. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 8: Operator Panel And Controls
When the desired amount of frozen fries have dispensed into the basket, the Dispense button is released, the Dispenser Drum stops rotating and the Outlet Door closes. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 9: Start Up And Operation
Diverter, and pulling it evenly toward the Hopper wall opposite the Diverter. 4. Remove the basket. This crisscross loading method assures an even distribution of fry lengths in the Hopper and the Baskets Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 10: Daily Closing: Disassembly, Defrost & Cleaning
2” (50 mm) defrost. behind the dispenser is recommended. Caution: Never use a sharp object to remove frost build-up. Never drill or otherwise puncture cabinet walls or top. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 11: Temperature Controller Operation And Menu Structure
To unlock the keys, once again press both the up and down keys for 3 seconds. The display will show Pon and the keys will be unlocked. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 12: Error Detection
WARNING! Do NOT change the temperature scale (Fahrenheit or Celsius) on the controller. WARNING! Only qualified and trained personnel should attempt repairs to any of the systems in the Dispenser. Call the Technical Support Line for service issues. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 13: Troubleshooting
Reassemble Hopper assembly Overfilling baskets incorrectly Drum continues to turn after the Verify Dispense Button is not sticking Dispense Button is released Suspect a faulty relay PCB. Call AE for assistance. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 14: Part Identification
Screw, Flat Head, Slotted, #8-32 x 1 In. 293434 Caster 200774 Screw, Hex-Head 5/16-18x3/4” 290012 Nut, Hex, 5/16-18 216159 Washer, 5/16 296533 Door Heater Wire (Dom.120V) shown 296511 Label Set shown Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... - Page 15 Description 291411 Probe, Temperature 291284 P-Clip 295234 Spacer 292058 Grommet 296525 Hopper 296178 Diverter 202366 Drum 295699 Hopper Support 293720 Screw, FH, Slotted 10-32x1" 293966 Rack, Hashbrown, Optional shown Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
- Page 16 Lower Back Panel shown 295653 Handle, Plastic 294824 Screw, Truss Head, #10-32 x 3/8” 296572 Terminal Block, Lower shown 296575 Harness,120VAC / 220VAC power shown 296576 Harness, 24VDC power shown Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
- Page 17 Description Item Part# Description 290133 Motor, Gear, 24 VDC 203249 Switch, Micro 296496 Bracket, Motor Mount 296493 Shaft, Door Drive shown 296495 Plate, Switch Mount 296500 Door Drive shown Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
- Page 18 Cap Screw, Socket HD, #10- 292546 Motor, Gear, Brushless, 24 VDC 213136 32x1¼” 202797 Bracket, Mount, Drum motor. 293318 Drum Shaft 213140 Washer, Lock, #10 290653 Set Screw, 3/8”-24 x 3/8” Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
-
Page 19: Refrigeration System
Caution: Never use a sharp object to remove frost build-up. Never drill or otherwise puncture cabinet walls or top. Wipe the cabinet dry and sanitize when defrost is complete. Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... - Page 20 O.D., 0.040” I.D. (International 240V 60HZ, 1/2 HP Comp.) 293907 Capillary Tube 122” (267cm) 0.093” per inch O.D., 0.040” I.D. (International 240V 50HZ, 1/2 HP Comp., R290 only) Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
- Page 21 RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers Refrigeration Circuit (404A Refrigerant) Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
- Page 22 RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers Refrigeration Circuit (R290 Refrigerant) Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
-
Page 23: Electrical Diagram
RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers Electrical Diagram Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 24: Specifications
Factory Temperature Set Point: 0°F (-18°C) Factory Differential Set Point: 4°F (3°C) High Pressure Switch: opens at 425 psi (2890 kPa), resets at 325 psi (2210 kPa) Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... -
Page 25: Service Information
All shipping charges are F.O.B. factory, and are subject to change without notice. Prices will be those in effect at the time of shipment. Automated Equipment LLC. reserves the right to make suitable substitutions in materials, depending upon their availability. -
Page 26: Disposal Of Equipment
You must understand and follow the proper procedures on the disposal of materials, such as refrigerants, insulation or plastics. CAUTION: Release of refrigerant into the atmosphere is strictly prohibited! Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19... - Page 27 RAM™ 16-F & 16-Fp Space Saver Frozen Fry Dispensers Notes: Copyright © 2019 Automated Equipment LLC All rights reserved. Published 8/19...
