Display User's Manual
Display User's Manual
Display User's Manual
LCGO21EAHBI
LCGO21EAHBI-INT
INT
21.5" Color LCD Display
Model No.: MSBP2131AW
MSBP2131AW
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSBP2131AW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Richardson Electronics MSBP2131AW

Summary of Contents for Richardson Electronics MSBP2131AW

  • Page 1 Display User's Manual Display User's Manual Display User's Manual LCGO21EAHBI LCGO21EAHBI-INT 21.5” Color LCD Display Model No.: MSBP2131AW MSBP2131AW...

  • Page 2: Table Of Contents

    Revision History The revision letter changes with related comments each time the document is updated. Revision Revision Comment Initial Contents 1. Information ................. 3 2. Equipment Symbols ..............9 3. Cleaning Instructions ..............11 4. Disposal of the Unit ..............11 5.

  • Page 3: Information

    1. Information Information Safety Precautions Safety Precautions CAUTION Symbol Description Symbol Description Caution!-This symbol alerts you to important operating considerations or a This symbol alerts you to important operating considerations or a This symbol alerts you to important operating considerations or a potential operating condition that could damage equipment.
  • Page 4 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may NOT cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 General recommendations ● Make sure to carefully read the Operating Manual prior to using the monitor in order to properly use the monitor. ● Note that, excluding those cases where a responsibility for legal compensation is recognized, the manufacturer shall bear absolutely no responsibility for damage to this product by a customer or a third party that results from the ignoring of contents entered in this Operating Manual and mistaken use.
  • Page 6  Suivez les instructions ci-dessous pour utiliser l'écran LCD en toute sécurité.  Pour éviter un choc électrique, ne tentez pas de retirer un couvercle ou de toucher l'intérieur du moniteur. Seul un technicien qualifié peut ouvrir le boîtier du moniteur. ...
  • Page 7  L'installateur doit prévoir un système de sauvegarde en cas de chute de la vidéo.  Cet équipement ne doit pas être réparé ou entretenu pendant son utilisation avec le patient.  ATTENTION : Pour éviter le risque de choc électrique, cet équipement doit être raccordé à...
  • Page 8 Users to be considered A) Installation personnel – only by manufacturer trained and authorized technician B) Maintenance/repair personnel – only by manufacturer trained and authorize technician C) Operating personnel – not in consideration for the graphical images at this stage As there are none to consider, however user interfaces such as OSD and control buttons shall be considered.

  • Page 9: Equipment Symbols

    2. Equipment Symbols Equipment Symbols Equipment Symbols Electrical and Electronic Equipment Symbols Electrical and Electronic Equipment Symbols Electrical and Electronic Equipment Symbols In addition to the equipment symbols described in your user's manual, In addition to the equipment symbols described in your user's manual, the following symbols the following symbols may be appear on the monitor.
  • Page 10 RFID antenna in front design. RFID antenna in front design. Indicates the manufacturing date Indicates the manufacturing date After – sale Service sale Service Richardson Electronics GmbH Richardson Electronics GmbH Raiffeisenstr. 5 D-78166 Donaueschingen 78166 Donaueschingen Germany...

  • Page 11: Cleaning Instructions

    3. Cleaning Instructions ● Be sure to unplug the power cord from the mains when cleaning your LCD monitor. ● Take care not to scratch the front surface with any hard or abrasive material. ● Dust, finger marks, grease etc. can be removed with a soft damp cloth (a small amount of mild detergent can be used on the damp cloth).

  • Page 12: Outline

    5. Outline Outline Front view Overview 2.2 Rear view Overview...
  • Page 13 Connector view DC 24V IN DC input 9-36V from external adapter from external adapter DSUB 15 pin connector, Use VGA cable to connect the VGA connector of the DSUB 15 pin connector, Use VGA cable to connect the VGA connector of the DSUB 15 pin connector, Use VGA cable to connect the VGA connector of the monitor and the VGA output connector from source device.(or DVI monitor and the VGA output connector from source device.(or DVI...
  • Page 14 Connector pin assignments Main board Input signal connectors Main board Input signal connectors VGA signal input Pin No. Signal Assignment Signal Assignment RED SIGNAL GREEN SIGNAL BLUE SIGNAL DSUB_5V DDC DATA H.SYNC V.SYNC DDC CLOCK DVI signal input Pin No. Signal Assignment Signal Assignment T.M.D.S.
  • Page 15 GROUND DP signal input Pin No. Signal Assignment Signal Assignment Lane 3 (negative) Lane 3 (negative) Ground Lane 3 (positive) Lane 2 (negative) Lane 2 (negative) Ground Lane 2 (positive) Lane 1 (negative) Lane 1 (negative) Ground Lane 1 (positive) Lane 0 (negative) Lane 0 (negative) Ground...
  • Page 16 USB HUB & Touch connector USB connector USB B-type 4 Pin (Upstream & Touch) PIN NO. Signal USB A-type 4 Pin (Downstream) ownstream) PIN NO. Signal DC 9-36V Power connector 9-36V input Pin No. Signal Assignment Signal Assignment +9-36V +9-36V...

  • Page 17: Operation

    6. Operation 5 Key Controls on rear cover : POWER,MENU, ▲ , ▼,ENTER Power: Press this button to turn the monitor on. When the monitor is on, press and hold this buttonfor 3 secondsto turn the monitor off. Menu: Press to open OSD menu. ▲...
  • Page 18 Clock Phase Back Language English Francais Deutsch Italiano Espanol 日本語 Transparency H.Position V.Position Timeout Back System Reset Back Info./ Exit Resolution :1920x1080 H.Freq :68KHz V.Freq : 60Hz V Total :1125Lines Color Format : RGB OP Hours: 0 Hrs...
  • Page 19 OSD selection Brightness/Contrast settings 1920x1080@6 0 Hz Brightness/Contrast Brightness Color Mode Contrast Input Source Back Display System Info./Exit Selecting this control allows you to make adjustment to the backlight dimming and contrast of the display screen by the range from 0 to 100. *Press up/down to adjust the brightness any time while the OSD is off Color Mode Settings 1920x1080@6 0 Hz...
  • Page 20 Color Temp. User 1920x1080@6 0 Hz Brightness/Contrast Color Temp. User Color Mode Input Source Green Display Blue Gamma System Info./Exit You can adjusts the gain of Red by the range from 0 to 100. Green You can adjusts the gain of Green by the range from 0 to 100. Blue You can adjusts the gain of Blue by the range from 0 to 100.
  • Page 21 Input Source select 1920x1080@6 0 Hz Brightness/Contrast Color Mode Input Source DisplayPort Display System Info./Exit You can select source from VGA ,DVI and DP. Display settings 1920x1080@6 0 Hz Brightness/Contrast Auto adjust Color Mode H.Position Input Source V.Position Display Clock Phase System Back...
  • Page 22 Clock Adjust the frequency sampling rate of horizontal pixels for VGA, to equal the video source’s value, thus minimizing artifacts of shimmering vertical lines. Phase Adjust ADC sampling clock phase for VGA, so that the screen image appear crisp and focused.
  • Page 23 SYSTEM Settings Normal Mode 1920x1080@6 0 Hz Brightness/Contrast Reset Color Mode Back Input Source Display System Info./Exit Reset Select this function to reset all OSD adjustments to the factory default settings Information Normal Mode 1920x1080@6 0 Hz Brightness/Contrast Resolution :1920x1080 Color Mode H.Freq :68KHz Input Source...

  • Page 24: Display Timing Modes

    7. Display Timing Modes Timing Table Resolution Frequency Input Signal Mode Name H(kHz) V(Hz) DisplayPort 31.47 59.94 35.16 56.25 SVGA 37.88 60.32 1024 48.36 SXGA 1280 1024 63.98 60.02 UXGA 1600 1200 1080P 1920 1080...

  • Page 25: Specifications

    8. Specifications Product name : 21.5" Color LCD Display Screen technology TFT active matrix type liquid crystal panel Active screen size (diagonal) 21.5” Active screen size 476.64mm (H) x 268.11mm (V) Aspect ratio (H:V) 16:9 Resolution 1920 x 1080 Pixel pitch 0.24825 mm Color support 16.7million...
  • Page 26 External Dimensions 21.5”...

  • Page 27: Contact Information

    Electronics GmbH Boschstr. 8 82178 Puchheim Germany www.canvys.de Technical Support / Service contact Canvys - Visual Technology Solutions A Division of Richardson Electronics Richardson Electronics GmbH Raiffeisenstr. 5 D-78166 Donaueschingen Germany Tel.:+49 (0)771 - 8300-0 Fax:+49 (0)771 - 8300-80 E-Mail: info-europe@canvys.com http://www.canvys.de...
