Summary of Contents for SMART J4
-
Page 2: What's In The Box
1. what’s in the box Please consult below checklist for all the components. Video Doorbell USB Cable User Guide Indoor Chime Screw & Tools Adhesive Tape 2. meet the doorbell 2MP camera LED indicator Security screw hole Micro-SD card slot Motion sensor Charging indicator Microphone... -
Page 3: Battery Installation
Download and install the 'CloudEdge' App from Google Play or the App Store . The App is also available by scanning the QR codes on the right, using your QR code scanner on your smart phone. NOTE: Google Play is a trademark of Google Inc. -
Page 4: Run A Test
Guiding steps: 9:55 9:55 9:55 9:55 Install Doorbell Install Doorbell Devices Install Doorbell Camera Doorbell Battery Camera Floodlight Camera Press the [Bell] button, and tap Next Please reset the device Please follow the instruction manual to power the device Help ·... -
Page 5: Live Viewing
9. Live viewing Wi-Fi signal status Quit live viewing Screenshot button Setting menu Speak to the scene Battery status Volume on/o Record on the phone HD/SD switch Body detection on/o Full screen display Noti cation history Stream bit rate Cloud storage service Note: Live viewing will not trigger device recording. - Page 6 11. leave Voice messages Maximum 3 voice messages (Max. 10 seconds each) can be pre-recorded into the doorbell, which enables you to quickly respond to your visitors when you are not convenient to answer the doorbell call. Steps: Setting --> Basic function -->...
- Page 7 Sharing by QR code scanning The new users can show their QR codes to the administrator, and share device by QR Code scanning. Find your QR code: CloudEdge App >> Tap on “ ” >> “User Name” >> “My QR Code”...
- Page 8 2). Click reset button 3). Press the doorbell button Reset Button LED Indicator Click the RESET button on the wireless chime only once, Press the doorbell button, and you will see the LED indicator ashing blue, and the Chime will sound to react. Pairing succeeds, indicating the chime is in pairing mode.
-
Page 9: Installation
14. Installation 166° Select location Your doorbell has 166-degree view angle and 120-degree human detection range. 5 feet 160cm It is suggested to mount your doorbell at least 5 feet (160 cm) above the ground for the best angle of view and motion detection performance. - Page 10 Go wireless installation The Smiths (Example) 1. Dismount the bracket by pushing from 2. Bracket installation: mount the bracket on 3. (Optional) The nameplate holder can be the back of your doorbell. Please remove the wall with screws & anchors or the double mounted on the top rear/ bottom rear of the the insulation lm in the battery cell.
-
Page 11: Speci Cation
15. Speci cation Video doorbell Indoor Chime Video & Audio General Image Sensor 1/2.7” CMOS (2.0MP) Power source DC 5V 1A Lite-OS Power port USB (Type-A) 1920 × 1080 px Resolution Consumption 0.2W Stream HD/SD dual stream Ringtones 4 ringtongs optional Infrared LED High power IR LED with ICR Volume... -
Page 12: Troubleshooting
16. Trouble shooting Q1: Why I failed to set up Wi-Fi for the doorbell? A1: .Device works with 2.4GHz Wi-Fi only, but not support 5GHz Wi-Fi. .Wi-Fi network is not good, try to keep the camera near the Wi-Fi router when setting up. .The Wi-Fi password is wrong. Please check if there are special characters in the password, or the network is specially encrypted.
