- Page 1 REACTOR IN THE HOME RANGE 230V INSTALLATION AND MAINTENANCE MANUAL UV_Home_(anglais) - DOC012472 - Ind. O03 - 27/04/2017...
-
Page 2: Table Of Contents
We thank you for choosing a BIO-UV reactor. Our equipment has been designed to give you reliable and safe operation for many years to come. According to the decree of the Health Ministry of the August 21 of 2008, concerning the case of rainwater collected on roofs treatment, this water can not be used for human consumption. -
Page 3: Technical Characteristics
A. TECHNICAL CHARACTERISTICS HOME RANGE UNIT HOME 2 -230V HOME 3 - 230V HOME 4 – 230V HOME 6 – 230V HOME 9 – 230V REACTOR Material 304L stainless steel 304L stainless steel 316L stainless steel 316L stainless steel 316L stainless steel... -
Page 4: Safety Warnings
B. SAFETY WARNINGS · Switch off the device 10 minutes before any intervention to let the lamps cool down. · Stop the system in the event of a prolonged stop of the water flow · Never expose yourself to the radiation of the ultraviolet lamps when lit. This may cause severe injuries or burns and may even lead to loss of eyesight. -
Page 5: Installation Guide
C. INSTALLATION GUIDE 1. Foreword BIO-UV reactors are ready to install, no works is required inside the reactor. It is necessary to read all the instructions in this manual before switching on the reactor. 2. Usage environment Location Room protected from direct sunlight and bad weather Ambient temperature between 0°C et 40°C Corrosive environment... -
Page 6: Instructions For Electrical Connections
· In horizontal position (outlet upward) Ø It is necessary to provide a sufficient space corresponding to the reactor length to be able to bring it out of its support easily. Ø The reactor should be installed: · as closest as possible from the water supply ·... -
Page 7: Filtration Kit Options
5. Filtration kit options a.) Mounting of the 2 filters kit for HOME 2 and HOME 3 Part code Designation Quantity ACC006536 Brass butterfly valve, ¾ male/female PIE004433 Filter support VIS004448 UV reactor fixing screw (2 per reactor) VIS004503 Zinc flat washer Ø6 VIS004504 Zinc nut Th M6 ACC004439... -
Page 8: B.) Mounting Of The 3 Filters Kit For Home 2 And Home 3
b.) Mounting of the 3 filters kit for HOME 2 and HOME 3 Part code Designation Quantity ACC006536 Brass butterfly valve, ¾ male/female PIE004434 Filter support VIS004448 UV reactor fixing screw (2 per reactor) VIS004503 Zinc flat washer Ø6 VIS004504 Zinc nut Th M6 ACC004439 Hose, stainless steel... -
Page 9: C.) Installation Procedure
c.) Installation procedure OPERATION Assemble the filter bowls (9.1/9.2/9.3) together, with the nipples(5), the rotary coupling(s) (6), the seals (7) and Teflon strip (T). According the connection type, the tightening of the connections wil be done with seals or Teflon strip (see exploded view) Warning ! : Comply with the direction of water circulation in the filters, marked with arrows and the words ‘IN’... -
Page 10: Option Uv Sensor And Pro3 Monitor
6. Option UV sensor and PRO3 monitor The PRO3 monitor only exist in 230V to plug on a wall socket This PRO3 monitor will indicate the drop in intensity of lamps during their lifespan and can also provide warning of fouling of the quartz duct or the UV-C radiation measurement cell. -
Page 11: Starting Up
D. STARTING UP First check the reactor and the electrical cabinet have been correctly installed (see C. Installation guide) Open the water supply and check there is no leak After the installation of the reactor BIO-UV on your installation, it can be necessary to carry out a “VACCINATION” of the piping: ·... -
Page 12: Procedure To Replace The Lamp, The Quartz Sleeve And The Seal
E. PROCEDURE TO REPLACE THE LAMP, THE QUARTZ SLEEVE AND THE SEAL Ø These operations must be carried out in case of: · Replacement of the lamp, quartz sleeve or seal · Checking/cleaning of the quartz sleeve · Alarm on the PRO3 monitor (option) The reactor MUST be SWITCHED OFF, ISOLATED, DRAINED, UNCLIPPED and INSTALLED VERTICALLY Unscrew the gland to release the lamp cable... - Page 13 Clean the quartz sleeve with acid or white vinegar or replace it if necessary. While remaining well aligned with the axis, introduce the quartz sleeve into the reactor to its guide at the end of the reactor. With your finger inside the sleeve position the quartz into the spring seat at the bottom of the reactor.
-
Page 14: Maintenance File
F. MAINTENANCE FILE CAUTION: This sheet must be kept up to date. It provides a record of the reactor’s operating cycle. Date Action done by UV_Home_(anglais) - DOC012472 - Ind. O03 - 27/04/2017 Copyright BIO-UV Marque, Modèles et Brevets déposés - Produits exclusifs Page 14... -
Page 15: Electrical Description
G. ELECTRICAL DESCRIPTION 1. Electrical unit REFERENCES HOME 2 - HOME 3 - HOME 4 - HOME 6 - HOME 9 - MARK DESIGNATION 230V 230V 230V 230V 230V Fuse support ELE000839 ELE000839 ELE000839 ELE000839 ELE000839 ELE001837 ELE001837 ELE001837 ELE001837 ELE001837 Fusible (5x20,1A) -
Page 16: Wiring Of An Alarm Contact On Pro3 Monitor Option
2. Wiring of an alarm contact on PRO3 monitor option The alarm contact is used to control a safety valve (no water flow), a buzzer, a light... when the alarm is triggered on the PRO3 monitor. It supports a maximum voltage of 230 V and a current of 1A. -
Page 17: Blown Up View With Uv Sensor Option
H. BLOWN UP VIEW WITH UV SENSOR OPTION REFERENCE MARK DESIGNATION HOME 2 HOME 3 HOME 4 HOME 6 HOME 9 Nut protection VIS004279 VIS004279 USI005243 USI005243 USI005243 Lamp socket ElE002603 ElE002603 ELE002603 ELE002603 ELE002603 Lamp LPE000003 LPE000004 LPE000005 LPE000005 LPE000006 Sealing nut USI004134... -
Page 18: Dimensions
I. DIMENSIONS Reactor DESIGNATION Flanges Dimensions in mm weight (kg) UV HOME 2 446 122 326 446 120 284 Male threaded 3/4’’ UV HOME 3 717 122 596 717 120 284 Male threaded 3/4’’ UV HOME 4 1067 159 871 1067 136 120 284 Male threaded 1’’... -
Page 19: Warranties
J. WARRANTIES Units in the BIO-UV range are guaranteed subject to the following conditions: 5 years for the stainless steel reactor (materials and welding) except in the event of use in a highly corrosive environment (brackish or very salty, e.g.: seawater, storage near to acid and corrosive products , use of acid hydrochloric).
