PIKO 56500 Quick Start Manual

CV

Description

1 Locomotive address
2 Minimum speed (the speed from 0 until the locomotive is running at speed step 1)
Acceleration delay,
1 means every 5 milliseconds the actual motor speed is increased by 1. If the maximum
3
motor speed is 200 (CV 5 = 50 or CV 94 = 200), then the acceleration rate from 0 to
maximum speed is 1 second
4 Braking rate (time factor like CV 3)
5 Maximum speed (must be greater than CV 2)
6 Average speed (must be greater than CV 2 and less than CV 5)
Software version (The processor can be updated)
7
8 Manufacturer identification decoder reset, values like CV 59
Decoder operating mode
Bit 0=1 DC (analog operation; direct current) on
Bit 2=1 DCC data format on
12
Bit 4=1 AC (analog 3-rail operation; alternating current) on
Bit 5=1 Motorola® data format on
Bit 6=1 mfx® data format on
Long locomotive address
17
17 = Byte should be lower-case: byte
18
18 = Byte should be lower-case: byte
Brake signal settings (automatic stop)
Bit 0 = 1 -> ABC (Automatic Brake Control) right rail positive
27
Bit 1 = 1 -> ABC left rail positive
Bit 4 = 1 -> DC; opposite direction of travel
Bit 5 = 1 -> DC; same direction of travel
DCC standard configuration
Bit 0=0 Normal direction of travel
Bit 0=1 Opposite direction of travel
Bit 1=0 14 speed steps
Bit 1=1 28 speed steps
Bit 2=0 DCC-only mode
29
Bit 2=1 Automatic analog/digital recognition
Bit 3=0 RailCom® turned off
Bit 3=1 RailCom® turned on
Bit 4=0 Speed steps over CV 2, 5, and 6
Bit 4=1 Use the characteristic curve from CV 67 - 94
Bit 5=0 Short address (CV1)
Bit 5=1 Long address (CV 17/18)
Error codes for function outputs, motor, and temperature monitoring:
30
1 = function output fault, 2 = motor fault, 4 = overload protection

Simple function mapping (DCC standard RCN-225)

Assignment of the function outputs to the CVs
CV 33 Light function key (F0) during forward travel
CV 34 Light function key (F0) during reverse travel
CV 35 function key F1
CV 36 function key F2
CV 37 function key F3
CV 38 function key F4
33-46
CV 39 function key F5
CV 40 function key F6
CV 41 function key F7
CV 42 function key F8
CV 43 function key F9
CV 44 function key F10
CV 45 function key F11
CV 46 function key F12
156 function key ABV off/on
157 function key shunting mode
* factory set values
PIKO Spielwaren GmbH
Lutherstr. 30
96515 Sonneberg
GERMANY
Area
DCC: 1 - 127
®
Motorola : 1 - 80
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
-
different
Value
*1
*4
0 - 117
*16
*32
*64
1 - 10239
192 - 231
0 - 255
Value
1
2
0 - 51
16
32
Value
*0
1
0
*2
0
*4
0-63
0
*8
*0
16
*0
32
0-7
Assignment of the
Fct. outputs
f0v
f0h
A1
A2
A3
A4
0 - 255
A5
A6
A7
-
-
-
-
-
0 - 68
0 - 68
56500-90-7001_2021
Value
3
0
30
NOTE: Detailed information on the PIKO SmartDecoder XP 5.1 is available as a PDF file on our Webshop
on the page of the respective item number. The file contains a full description of all functions and
30
operating possibilities for the new SmartDecoder XP 5.1.
200
100
Description
differently
The state-of-the-art PIKO SmartDecoder XP 5.1 inside in this PIKO locomotive is a compact yet powerful multi-protocol
162
PluX22 decoder. It complies with the current RCN standards in all areas and can be used in DCC, mfx® and Motorola®
digital systems. The decoder can be used on DC or AC analog layouts. It automatically senses what operating mode
is used on your layout and is RailCom®/RailCom Plus® compatible. The SmartDecoder XP 5.1 features several
117 programmable braking distance functions in addition to numerous other programmable functions.
The PIKO SmartDecoder XP5.1 Sound is load-regulated and features auto-adaptive motor control that works with of
a fundamentally newly developed traditional DC motors for a silky smooth ride as well as 1.2 Amp coreless motors.
1000
The decoder will also tolerate a temporary current draw up to 2 Amps. The motor speed table can be set using the
195
minimum, median, and maximum motor speed (simple curve), or by the user-programable 28-speed step extended
232
curve. The decoder features two directional lighting outputs and seven additional special function outputs that can be
activated using function keys up to F68 (DCC). The switching (shunting) gear, with extended slow speed range, the
three possible starting and braking delays, as well as the many vehicle sounds are also switchable via function keys.
0
The sound of a suitable SUSI sound module can control specified function outputs as well as the motor output of the
decoder. For example, the lighting of a diesel locomotive flickers when the engine is started. The PIKO SmartDecoder
XP 5.1 is supported by the further developed power management in case of short-term voltage loss.

Installing the PIKO SmartDecoder XP 5.1

Remove the jumper plug from your model's PluX22 interface. Insert the new decoder into the interface socket. Note that
PIN 11 is missing on the new decoder. Check for crossed wires and short circuits before and after reinstalling the shell.
Place the model on your programming track with programming mode activated on your DCC system. During programming
or when reading the model's DCC address, a small amount of current will flow through the model, which does not affect
14
the decoder; even in the event of a short circuit.

Special functions A1 to A7

The decoder's special function outputs A1 to A7 can only be activated if the desired functions are already connected to
the model's PluX22 interface or if solder pads are available for the special function outputs on the main circuit board.
A short circuit in the motor, lighting, pick-up wiper, or wheelsets can destroy the
0

SUSI interface

1
The decoder's SUSI interface is controlled by the PluX22 interface. If the main circuit board of the model is equipped
2
with a SUSI interface, you can either use a PIKO sound module with SUSI or a suitable single-function decoder. You
4
can find which CV should be programmed for its respective function output in the operating instructions. The decoder
8
is factory set to send data to the PIKO sound module via the SUSI interface.
16
4
CAUTION: Soldering the decoder itself should only be done by experienced DCC professionals using appropriate
8
equipment. Decoders damaged by improper handling are not covered by the warranty.
16
32

First-time use of the decoder (state of delivery)

64
16 Enter address 3 on your DCC control system. Depending on your DCC system's data format, the decoder will
operate using 28 speed steps or in Motorola® mode. When using a RailCom Plus®-enabled DCC system or with
32
64 an mfx®-capable system, the decoder is recognized in a few seconds and can be operated immediately. If the
128
decoder is used on a conventional analog layout, it can be controlled with a DC or AC power pack. The decoder will
automatically detect the layout's operating mode.
9
NOTE: In DC analog mode, your model will only start at a higher voltage than what you may accustomed to when
8
operating analog models. You will need to turn the throttle up for the model to start operating.
Function Outputs in analog mode
It is possible to program the decoder so that function keys F0 - F12 (as they are assigned in the function mapping)
can also be activated in analog mode. To do this, CVs 13 & 14 must first be programmed with a DCC central control
unit. The corresponding values can be found in the CV table of the detailed operating instructions. The light function
F0 is factory-set to "on."
#56500
PIKO multiprotocol SmartDecoder XP 5.1 PluX22
mfx® capability included
decoder as well as the electronics of the model!
