- Page 1 Network Attached Storage TeraStation Hard Drive Operating Guide www.buffalotech.com 35011930-03 2013-10...
-
Page 2: Table Of Contents
Access Restrictions on External Drives ....................11 Chapter 3 Removing Hard Drives ..............12 Dismounting with the Function Button ....................12 Dismounting from Settings ........................13 Chapter 4 Managing your TeraStation ............14 RAID Scanning ..............................14 Disk Check ................................15 Encrypt Hard Drives on the TeraStation ....................15 Formatting Disks ............................16... -
Page 3: Chapter 1 Changing Raid Modes
• RAID 6 RAID 6 is available for TeraStation models with 4 or more hard drives. It combines 4 or more drives into a single array. It generates parity during writes, so access speeds are slower than other RAID modes. The usable space is equal to the sum of the capacity of the hard drives minus the capacity of two drives. - Page 4 • RAID 50 RAID 50 mode is available for TeraStation models with 6 or more hard drives. RAID 50 combines 6 or 8 drives into a single array. In this mode, two RAID 5 arrays are combined into a RAID 0 array. It generates parity during writes, so access speeds are slower than other RAID modes.
-
Page 5: Using Jbod
Using JBOD With JBOD, each hard drive in the TeraStation is addressed separately. To put drives from an array into JBOD mode, follow the steps below. In Settings, navigate to System - Storage - RAID Array. Select the array you want to configure. -
Page 6: Creating A Raid Array From Jbod
2 Click Create Raid Array. Note: After the RAID array is changed (except when creating a RAID 0 array), the TeraStation will perform a RAID check that will take about 10 hours per TB. File transfers will be slower during this period. While the “RAID I17 ARRAYx Resyncing”... -
Page 7: Configuring A Hot Spare
Configuring a Hot Spare If one of the drives in the array fails, the TeraStation will switch over to the hot spare immediately. You can configure another drive as a hot spare if the following condition are met: • There is an extra drive not used in the array. -
Page 8: Rmm (Raid Mode Manager)
Notes: • After the RAID array is changed (except when creating a RAID 0 array), the TeraStation will perform a RAID check that will take about 10 hours per TB. File transfers will be slower during this period. While the “RAID I17 ARRAYx Resyncing”... - Page 9 2 After adding the drive, click your desired RAID mode for the RAID array. Note: After the RAID array is changed (except when creating a RAID 0 array), the TeraStation will perform a RAID check that will take about 10 hours per TB. File transfers will be slower during this period. While the “RAID I17 ARRAYx Resyncing”...
-
Page 10: Chapter 2 Adding An External Hard Drive
Connect an External Drive Your TeraStation includes USB ports. You can connect a Buffalo external hard drive to it for backup or extra storage. If the hard drive is already formatted, it will be detected automatically. If it is not formatted, format it from within Settings. -
Page 11: Formatting The External Drive
Follow the instructions displayed on the screen. Notes: • The info LED on the front of the TeraStation will flash during formatting. The TeraStation’s shared folders cannot be accessed until the disk format is complete. • If the hard drive is connected to the USB connector, partitions will be recreated. -
Page 12: Access Restrictions On External Drives
USB mice and keyboards. • You can connect one hard drive to each USB port. Only Buffalo drives are supported. • Set the power mode for drives connected to the TeraStation to “manual”. Drives in “auto” power mode may not be recognized. -
Page 13: Chapter 3 Removing Hard Drives
To dismount a USB drive, press and hold the function button for 7 seconds. The function button will be illuminated in blue (The LED next to the function button will be illuminated in blue on a rackmount TeraStation). After the light in the function button goes out, you can safely remove your USB device. -
Page 14: Dismounting From Settings
When the Confirm Operation screen opens, enter the displayed number within 60 seconds and click Apply. The function button will glow blue (on the rackmount TeraStation, the LED next to the function button will glow). Remove the drive within 30 seconds. -
Page 15: Chapter 4 Managing Your Terastation
RAID scanning allows regular scans of your RAID arrays to be configured to run automatically. Errors will be fixed as they are found if possible. For best results, schedule regular RAID scans if you use RAID arrays in your TeraStation. 1 In Settings, click System - Storage - RAID Scanning. -
Page 16: Disk Check
Disk Check A disk check tests the data on a drive in the TeraStation or connected via USB. Errors are fixed automatically. A disk check may run for more than ten hours. Shared folders cannot be accessed during the disk check. Do not turn off power to the TeraStation during the disk check. -
Page 17: Formatting Disks
• A format may take anywhere from a few minutes to several hours depending on the size of your drives. • The message “Formatting” will be displayed on the LCD panel during formatting. The TeraStation’s shared folders cannot be accessed until the disk format is complete. -
Page 18: Media Cartridge System
Follow the instructions displayed on the screen. Notes: • The message “Formatting” will be displayed on the LCD panel during formatting. The TeraStation’s shared folders cannot be accessed until the disk format is complete. • A format may take anywhere from a few minutes to several hours depending on the size of your drives. -
Page 19: Chapter 5 Extensions
Direct Copy automatically copies movie, music, and images directly to the TeraStation from a USB device. You can connect many types of USB devices to the TeraStation, including USB hard drives, USB flash drives, single-card card readers, digital cameras, and USB printers. USB hubs, mice, keyboards, and card readers that support 2 or more cards are not supported. - Page 20 When the access LED of the USB device goes off, the copy is finished. Dismount the USB device before unplugging it. To dismount the USB device if the TeraStation is on, hold in the function button for 6 seconds. The blue LED will go out, and the USB device is dismounted. You may now unplug it safely.
-
Page 21: Disk Quotas
• Quotas apply per drive or per array. If a quota is set to 1 GB, each array or drive can use maximum of 1 GB. • Quotas can’t be set for external USB hard drives connected to the TeraStation, only internal drives. - Page 22 Select Shared Folders - Folder Setup and click Create Folder. 1 Configure the desired settings. 2 Click Access Restrictions. Click Add. 1 Check the user you created in step 2. 2 Click Add. Select level of access privileges for the user you added from Read Only or Read &...
- Page 23 Disk space quotas for groups To limit the space of shared folders that each group can use, follow the procedure below. 1 In Settings, select Users/Groups - Local Users. 2 Click Create User. 1 Enter Username, User Id, Password and Description. Note: User IDs may be between 1000 and 1999.
- Page 24 1 Enter Group Name, Group Id and Description. Note: The group ID may be any number from 1000 and 1999. Do not duplicate Group IDs. 2 Click Enable for Group Quota. 3 Enter the total space that the group can use in the Hard Limit (GB) field. 4 Select users from step 2 in Local Users, and click Add for each.
- Page 25 1 Click Local Groups. 2 Click Add. 1 Check the group you created in step 4. 2 Click Add. Select level of access privileges for group you added from Read Only or Read & Write. Click Save. You have configured a group quota.
-
Page 26: Enable/Disable Lvm (Logical Volume Manager)
Enable/Disable LVM (Logical Volume Manager) LVM is disabled by default. Enabling LVM will allow you to divide volumes and extend capacity, but will degrade access speeds. Notes: • Changing the operation mode of a disk or array (such as enabling LVM) will delete all volumes and data from the disk or array. -
Page 27: Create Volumes
Create Volumes Notes: • Deleting the default volume will delete all data from the TeraStation. Back up any important data before making any configuration changes! • Enable LVM to delete or create volumes. 1 In Settings, navigate to System - LVM Volume. -
Page 28: Extending Volumes
Extending Volumes The available space on a volume can be extended after you create the volume. Notes: • Extending the volume may delete all data on the volume with some file systems. Before extending the volume, back up any important data on the volume. •...
