Product specifications
Screen
Monitor
Model number
Resolution
Brightness
Viewing angle
Response time
Connector
USB-C
Mini HDMI
User controls
Control keys
Power
Input
Power consumption Boot up 5W
Entity
Device dimensions
Device weight
Environment
Temperature range
Relative humidity
13.3-inch TFT LCD, LED backlight
1920 x 1080
300 cd/m2
Horizontal 178°, vertical 178°
Tr+Tf: 25ms (typical) / 50ms (maximum)
USB-C x2 (both input)
Mini HDMIx1
None
DC5V/2A, USB power supply
344 mm x 210 mm x 7 mm
Net weight 0.815 kg, total weight 1.45 kg
Operation: 0°C – 40°C
Storage: -10°C – 60°C
Operation: 20% – 80%
Storage: 10% – 90%
Operation: 20% – 80%
Storage: 10% – 90%
8
