- Page 1 ID1330 ViewBoard Pen Display User Guide Model number: VS18342...
- Page 2 As a leading global visual solution provider, ViewSonic® is committed to exceeding the global expectations for technological evolution, innovation and simplicity. At ViewSonic®, we believe that our products may cause a positive impact to the world, and we are confident that you will be satisfied with the ViewSonic® product that you chose.
-
Page 3: Important Safety Instructions And Recycling Tips
Important safety instructions and recycling tips Do not press the screen; do not store this device together with small objects, otherwise the screen may get scratched easily or small objects might fall inside the device. Do not place this device in dirty or dusty environments; keep the environment dry and clean. -
Page 4: Table Of Contents
Table of Contents Important safety instructions and recycling tips ..3 Product introduction ........... 6 About the product ................... 6 The product and its accessories ................ 7 System requirements ..................7 Product specifications ..........8 Screen ......................8 Electromagnetic pen ..................9 Accessory descriptions .......... - Page 5 Tablet function settings ..........19 Settings guide under Windows systems ............19 Opening the tablet settings panel ................. 19 Settings panel options ................... 19 Settings guide under Mac systems ..............20 Opening the digital control panel ................20 Control panel settings options ................20 Control panel: Pen (electromagnetic stylus function) ...........
-
Page 6: Product Introduction
Product introduc�on About the product Thank you for choosing Notas series products. This product will bring you all new visual effects – not only will it display the outstanding advantages of LCD, it even integrates advanced tablet technologies. Users can connect it to a computer and perform input and drawing operations on the screen with the electromagnetic pen directly, and apply it in multimedia teaching and related fields. -
Page 7: The Product And Its Accessories
Pen holder (includes refill and pen picker) If the accessories described above are missing or damaged, please contact your purchasing store; if the problem cannot be solved, please contact the after-sales service center of ViewSonic. System requirements Operating system: • PC:Windows 7/8/10(32/64bit) •... -
Page 8: Product Specifications
Product specifications Screen Monitor Model number 13.3-inch TFT LCD, LED backlight Resolution 1920 x 1080 Brightness 300 cd/m2 Viewing angle Horizontal 178°, vertical 178° Response time Tr+Tf: 25ms (typical) / 50ms (maximum) Connector USB-C USB-C x2 (both input) Mini HDMI Mini HDMIx1 User controls Control keys... -
Page 9: Electromagnetic Pen
Electromagnetic pen Model number Technical method Electromagnetic touch control Active area Full screen Technical specifications Resolution 5080 LPI (lines per inch) Tracking speed 266 PPS (points per second) Pressure sensitivity 8192 Accuracy ± 0.25 mm (center), ± 0.25 mm (edges and corners) Readable height 15 mm Electromagnetic pen... -
Page 10: Accessory Descriptions
Accessory descriptions Electromagnetic pen Note: • Users can set the key functions manually for the first and second pen keys, please refer to Chapter Five “Pen Key Setting Instructions” of the manual for the specifics. • Do not pull out the pen cover in any way. -
Page 11: Refill Replacement
Refill replacement Refill replacement steps 1. Use the refill changer to remove the refill from the pen body 2. Place the new refill into the pen head to replace with the new refill... -
Page 12: Hardware Installation And Commissioning
Hardware installation and commissioning Hardware installation How to connect the tablet Connecting using the HDMI+USB cables 1. Please first switch off the power of the computer and tablet before connec�ng the tablet. 2. Connect the HDMI cable to the HDMI interface of the tablet and the HDMI interface on the graphics card of the computer. -
Page 13: Connec�Ng Using The Type C Data Cable
Connecting using the TYPE C data cable 1. Please first confirm that your computer is equipped with full function TYPE C interface or Thunderbolt 3 interface. 2. Connect the double-sided TYPE C cable to the full function TYPE C interface of the tablet and the full function TYPE C interface of the computer. -
Page 14: Hardware Commissioning
Hardware commissioning Replacing mouse operations with the electromagnetic pen After the tablet is connected to the computer properly, the following operations can be used before installing the drivers: • Moving the cursor Suspend the electromagnetic pen (of a distance less than 15 mm) and move it on top of the sensing area of the tablet to move the cursor. -
Page 15: Osd Control Key Descriptions
OSD control key descriptions LED indicator Power switch key Menu key or OK key • LED indicator: Green means power on and red means no video signal • POWER key: Power switch key... -
Page 16: Osd Control Key Descriptions
OSD control key descriptions • Brightness adjustment: Adjusts the display brightness/contrast/ECO mode/ dynamic contrast SB signal output jack of the screen • IMAGE: Adjusts the screen display position output jack • COLOR TEMP: Adjusts the screen display RGB color gamut output jack... - Page 17 • OSD SETTING: OSD display frame setting, allows adjusting the language/position/ display time/transparency • RESET: Allows resetting to the default factory settings and adjusting the USB signal output jack...
-
Page 18: Driver Installation
Driver installation under Windows systems 1. Visit the official website of ViewSonic ( www.viewsonic.com) and download the complete Windows system driver package. Decompress it then double-click and run the “.exe” file; follow the steps until installation is completed, then restart the computer. -
Page 19: Tablet Function Settings
Tablet function settings Settings guide under Windows systems Opening the tablet settings panel There are two ways to open the tablet settings panel: • Tap on the small digital setting panel icon ( ) (the icon is located in the bottom-right corner of the computer system taskbar) to open the digital settings panel. -
Page 20: Settings Guide Under Mac Systems
• Express Keys: Customize settings for the function options of the 6 express keys on this device. Settings guide under Mac systems Currently there is only the English version tablet driver for Apple systems; its functions are similar to the driver functions under the Windows system. Users can refer to the driver settings introduction under Windows systems in the manual. -
Page 21: Control Panel: Pen (Electromagnetic Stylus Function)
Control panel: Pen (electromagnetic stylus function) Under this option, users can customize the function parameter settings used on the electromagnetic pen, set the functions of two keys, and perform a pressure test for the electromagnetic pen. Control panel: Mapping (screen calibration) Under this option, users can use screen calibration to confirm the corresponding screen area. -
Page 22: Control Panel: Express Keys (Express Key Settings)
Control panel: Express Keys (express key settings) Click “Express Keys” to enter the express key settings page; users can customize the functions according to the hints on the page and the express keys on the tablet. -
Page 23: Uninstalling The Drivers
Uninstalling the drivers Uninstalling the drivers under Windows systems There are two ways to uninstall the drivers: • Open “Start” → “All programs” → “DigitizerWhiteboardManager” → “Uninstall”, and follow the uninstall instructions until the uninstall program ends; then restart the computer. •... -
Page 24: Uninstalling The Drivers Under Mac Systems
Uninstalling the drivers under Mac systems • Open “Finder” → “Apps” → “Tablet Utility” → “Uninstall-Driver”, follow the uninstall instructions until uninstall program ends; then restart the computer. Note: After the driver was successfully uninstalled, if the driver needs to be reinstalled again, please restart the computer first to ensure that the driver was fully uninstalled. -
Page 25: Common Issues
Common Issues • How to find out whether the driver was installed properly? After the driver was properly installed, when the tablet and computer are connected properly, a small driver icon ( ) will appear on the taskbar of the computer. When the electromagnetic pen is used on the tablet, it will be able to control the cursor properly, and it will be able to sense pressure during the pressure test in the driver control panel. -
Page 26: Regulatory And Service Information
Regulatory and Service Information Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance... -
Page 27: Indian Restriction Of Hazardous Substances
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®... -
Page 28: Copyright Information
VESA is a registered trademark of the Video Electronics Standards Association. DPMS, DisplayPort, and DDC are trademarks of VESA. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 29: Customer Service
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/ Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/... -
Page 30: Limited Warranty
How long the warranty is effective: ViewSonic® displays are warranted for between 1 and 3 years, depending on your country of purchase, for all parts including the light source and for all labor from the date of the first consumer purchase. - Page 31 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
- Page 32 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
-
Page 33: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &... - Page 34 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
- Page 35 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
- Page 36 C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...
