- Page 1 User Manual 3 Gallon Bowl Refrigerated Beverage Dispensers Model: 177D3G1, 177D3G2, 177D3G3 08/2020 Please read and keep these instructions. Indoor use only. www.AvantcoRefrigeration.com...
-
Page 2: Table Of Contents
User Manual TABLE OF CONTENTS SAFETY ........1 FEATURES &... -
Page 3: Features & Controls
D3G1 D3G2 D3G3 MADE IN ITALY Bowls Capacity 1 x 3 Gal 2 x 3 Gal 3 x 3 Gal ITEM: 177D3G1 MODEL: COLDREAM 1M R134a DESCRIPTION : REFRIGERATED BEVERAGE DISPENSER Width 7.9 in 14.7 in 23.6 in VOLTAGE: 120V... -
Page 4: Installation
User Manual INSTALLATION UNPACKING In order to prevent the oil contained in the air-tight compressor from flowing into the cooling circuit, it is necessary to always carry, store, and handle the machine in a vertical position, following the instructions found on the packaging. If the machine was accidentally or purposely placed in a non-vertical position during transport, before operating the machine it should be kept in a straight position for approximately 30 minutes to allow the oil to flow back into the compressor. -
Page 5: Operation
User Manual OPERATION Before using the machine, all food contact surfaces and components must be cleaned CAUTION and sanitized in accordance to the Washing & Sanitizing section of this manual. PREPARING THE PRODUCT Concentrate In order to obtain a homogeneous mix, the product will need to be pre-mixed before being added to the machine. -
Page 6: Cleaning
User Manual CLEANING CAUTION The machine must be turned OFF and unplugged from the power source before cleaning. DISASSEMBLY (Fig. 7) Fig. 7 1. Lift the lid off. 2. Pull the mixer off. 3. Lift the container with both hands with a light, swinging motion. Should you have difficulty, it may be necessary to dampen steel refrigerator and gasket, then repeat the operation. -
Page 7: Troubleshooting
User Manual TROUBLESHOOTING CAUTION Problems marked with this symbol must be handled by a specialized technician. PROBLEM CAUSE SOLUTION The Main Switch is not set to I Set the Main Switch to I The machine is not plugged in Plug the machine into the outlet The machine does not turn ON Electric cable defective... -
Page 8: Electrical Diagram
User Manual ELECTRICAL DIAGRAM - D3G1/2/3 Compressor Exchanger Fan motor Boiler collector E 1,2,3 Evaporator Distributor Capillary Drain Line Liquid Line Suction Line Thermostat 8 www.AvantcoRefrigeration.com... -
Page 9: Parts Diagram
User Manual PARTS DIAGRAM - D3G1/2/3 CODE DESCRIPTION Stainless Steel Tap Assembly Push Lever Bowl Gasket Mixer Guiding Shaft Gearbox 110V Gearbox 220V Thermostat Red Switch Black Switch 0193,00 Side Panel Grey 0193,01 Side Panel Red 0193,02 Side Panel Blue Compressor 220V Compressor 110V 0067,02... - Page 10 User Manual Limited Warranty • 1. Warranty Against Defects: AVANTCO warrants its Defects or damage caused by carelessness or equipment to be free from defects in material and because the equipment was improperly installed or workmanship. set-up, or was used or operated in a manner contrary to the manufacturer’s operating instructions or...
