CSSN ScanShell 1000N Specifications

ScanShell 1000N
The Scanshell 1000N is a 5" x 3", Twain-compatible, portable
flatbed scanner. Offering color (24 bit), grayscale (8 bit), black
and white, and filter infrared spectrum inks scanning capability,
the Scanshell 1000N provides a convenient way to quickly
inspect secure documents such as passports, driver licenses,
bank checks/documents, ID cards, photos, and digital
"watermarked" items
The Scanshell 1000N works with any standard USB port and requires no external power adapter. Compact
and easy-to use, the Scanshell 1000N integrates seamlessly into corporate and government security
communities USA PATRIOT ACT compliance programs.

Features:

Light-weight and fully portable
Small footprint
No external power required
Scans filter infrared spectrum inks
Twain-compatible

Specifications

Interface
Image Sensor
Resolution
Scanning Modes
Scan area
Scan speed
Scanner Weight
Dimensions (LxWxH)
Cable length
Power consumption
Paper Thickness
Regulatory requirement
© 2005 All rights reserved to CSSN card scanning solutions
USB Full Speed (1.1)
Contact Image Sensor with RGB & IR light source
600 dpi
Monochrome, Color & IR filter
5" x 3"
3 to 12 seconds
20 oz.
8.6" x 6.1" x 1.7"
Detachable 36"
USB powered ( 2.0 W @ 5Vdc)
Unlimited – flatbed design
FCC & CE
(1)

Physical Dimensions

Height 1.65 inch / 42mm
Width: 6.1 inch / 155mm
Length: 8.64 inch / 219.5mm
Weight: 1.2 pound / 575gr
