- Page 1 PEUGEOT Anti -Theft Radio Manual...
- Page 2 PROGRAMMED RADIO STATION FREQUENCIES The programmed station memory will be erased in the event that power to the radio is disconnected due to electrical system repairs or due to low battery voltage for more than approximately one week. Therefore, record the frequen- cies of your favorite stations IN PENCIL above, for reprogramming when power is restored.
- Page 3 DEAR PEUGEOT OWNER: You have now purchased one of the finest, most stylish, and most comfortable automobiles manufactured today. For your listening comfort, your Peugeot is equipped with a digital, electronically tuned, AM/FM stereo radio with an auto- reverse cassette, equipped with Dolby B* noise reduction. Control placement and operation have been carefully engineered to minimize the time your eyes are off the road, thereby contributing to active safety.
-
Page 4: Description Of Features
DESCRIPTION OF FEATURES Full logic computer controlled. Anti-theft electronic code protection system Negative crystal display for all tape and radio liquid Electronic radio tuning functions. Digital phase-locked loop frequency synthesizer. Front/rear fader. Locks onto precise broadcast frequency to prevent drift. "Key off"... - Page 5 THE PEUGEOT THEFT DETERRENT PROGRAM The elements of the Peugeot Theft Deterrent Program have been designed in cooperation with law enforcement authorities to not only help thwart theft of your radio, but to also reduce the market for stolen radios.
- Page 6 DESCRIPTION OF FEATURES Full logic computer controlled. Anti-then electronic code protection system Negative liquid crystal display for all tape and radio Electronic radio tuning functions. Digital phase-locked loop frequency synthesizer. Front/rear fader. Locks onto precise broadcast frequency to prevent drift. "Key off' tape pause.
- Page 7 4. If the “anti-theft” radio identification cards are lost, etc., contact a Peugeot dealer of your choice. You may be charged for labor to remove and reinstall the radio to ascertain the radio...
- Page 8 WARNING: Proof of vehicle ownership and proper identification (valid driver’s license) must be verified by Peugeot dealer personnel. This information must be given by authorized dealer person- nel only to Peugeot Motors of America before radio “anti-theft’’ codes will be released by Peugeot Motors of America. This is necessary for your protection.
- Page 9 RADIO MODE CONTROL OPERATION AND LOCATION ON/OFF, VOLUME LIQUID CRYSTAL DISPLAY OF PUSH-SCAN UPSCALE (TO SCAN DOWNSCALE, PRESS"< T U N E AND THEN PRESS AM/FM I N D I ATORS VOLUME CONTROL) ST-STEREO PULL AND ROTATE TATION INDICATOR FRONT/REAR PRE-SET RADIO STATION PUSHBUTTONS TIONS TO PRO GRAM ON TREBLE...
-
Page 10: Radio Mode Operation
RADIO MODE OPERATION 3. SEEK For "onestep" reprogramming of preset radio station The radio will automatically tune to the next station of pushbuttons: ">" sufficient strength if the "seek buttons" in either the "<" (upscale) or (downscale) directions are pressed. a. - Page 11 TAPE MODE CONTROL OPERATION AND LOCATION D l S P S: 1 SIDE 1 (TOP) ON/OFF VOLUME PRESS 1 REVERSE TAPE PROGRAM (DIRECTION) 2 = SIDE 2 (BOTTOM) PUSH-TAPE FORWARD SCAN 70µs EQUALIZATION PRESS FOR REWIND (REW) PRESS AGAIN TO CANCEL "REW' CLEAN INSERT TAIPE MECHANlSM...
- Page 12 beginning of each selection. The selection will play for TAPE MODE OPERATION seven seconds and then fast forward to the next selec- tion, etc. To stop "scanning," press the volume control 1. COMPUTER CONTROL again.Tape Scan does not work in the"rewind" direction. The insertion of a cassette with the radio "on"...
-
Page 13: Maintenance
PRECAUTIONS 1. Use only high quality C60 tapes. C90 and C120 tapes are of insufficient thickness and therefore lack the strength to cope with the extreme variations in vehicle interior temperatures encountered. 2. Always place your tapes into their individual plastic case and store them in a multi-cassette holder to protect them against dirt, dust, and excessive heat from direct exposure to the sun, etc. -
Page 14: Specifications
SPECIFICATIONS AM Radio Power Amplifier Frequency Range 530 kHz-1620 kHz Maximum Output 4.4 W x 4Ch into 4 Ω Intermediate Frequency 450 kHz Output load 100 Hz to Sensitivity 20 dB S/N µ 20,000 Hz at 1 % Selectivity 50dB(+10kHz) Total Harmonic Distortion 0.1 % at 1 W Frequency... - Page 15 NOTES:...
- Page 16 i-T hef Radio Identification Card If "beep" heard while entering code. stop and begin code entry again 5 3 1 4 2 Anti-Theft Code Radio Your Serial Number...
- Page 17 PEUGEOT 68P81 707F12-0 Printed in Japan...
