Nmea Test - NetWave NW6000 Installation, Operation And Maintenance Manual

It is required by clicking anywhere on the screen that the picture will zoom into the original display
size. Clicking once again will provide the buttons. You can pan around the picture and 'pass' or
'fail' can be pressed. Outcome will be recorded in the logging.

1.2.4 NMEA test

When choosing NMEA on the OPT screen it will provide all connected NMEA sources.
Selecting one of the main categories will provide the following sensors:
BACK PASS FAIL
2014/12/04 11:18:45 UTC
NAVIGATION
ENGINE
FIREDOORS
NIGHT
BACK SELECT
2014/12/04 11:18:50 UTC
GPS – DECK
DEPTH – DECK
SPEED – DECK
AIS – DECK
HEADING 1 – DECK
HEADING 2 - DECK
NIGHT
BACK SELECT
PAN
ZOOM
# ALERTS: 3 NMEA
DOWN UP
# ALERTS: 3 NMEA
UP
DOWN
