CNET CNIG-914 Specifications

TOTAL NETWORK SOLUTIONS
CNIG-914(D) is the latest CNet broadband gateway enabling an entire network to access the Internet using a
high speed ADSL or Cable Modem connection. The router is equipped with a built-in firewall for protecting the
LAN clients from outside intruders as well as features to control Internet access for users in the Local Area
network.

KEY FEATURES

Provides four 100/10Mbps switch ports with auto MDI/MDI-X RJ-45 connectors.
Complete web management using standard internet browser.
Dynamic Host Configuration Protocol (DHCP) support.
Internet sharing Static IP, Dynamic IP., PPPoE, PPTP Client
VPN Pass Through (IPSec/PPTP)
Supports SPI Anti-DoS Firewall, URL, Port, MAC and IP address Filters.

SPECIFICATIONS

Model
Standards
Ports
Media Support
LED Indicators
Power
Environment
Certifications
CNIG-914 (D)
Specifications are subject to change without notice
CNIG-914 Internet Broadband Gateway
IEEE 802.3u: 100BASE-TX
IEEE 802.3: 10BASE-T
One Reset Button
WAN: One 10./100 RJ-45 Port for Cable/DSL Modem
LAN: Four 10/100 RJ-45 switched Ports
Category 5 Ethernet Network Cabling or better
Power: Green
Status: Green
WAN Link/Activity: Green
LAN Link/Activity: Green
External DC9V 0.8A
Operating Temperature: 0 ~ 45 C (32 ~ 113 F)
Storage Temperature: -20 ~ 70 C (-4 ~ 158 F)
Humidity: 10% ~ 90% Non-Condensing
CE, FCC
www.cnetusa.com
CNIG-914 (D)
Trademarks & Trade Names belong to their owners
April 2004
