- Page 1 User Manual IA-3126-2 16 Relays 16-ch Wide-Range inputs IA Daisy-chain Series Version 0213 www.intelligent-appliance.com...
- Page 2 Email: sales@Intelligent-Appliance.com Feedback We at Intelligent Appliance highly value your opinion. Please feel free to contact us with your impression on any subject, or with any question you may have. Warning Intelligent Appliance products are NOT authorized for use as components in life support devices or systems.
-
Page 3: Table Of Contents
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance Contents Introduction..................Specifications..................System Wiring..................Pin assignment.................. Software Instolation................. Command set................Get device name..........Get device firmware version......... Get I/O status............Get JP & LED Status..……………..... Get device mode.......... -
Page 4: Introduction
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance Introduction The IA-3126-2 is an indutrial intelligent 16-ch Relay Control Board, with 16-ch Digital Input and multi-drop operation capability, in the original IA-3131 foot print. The IA-3126-2 is an Industrial grade relay controller, easy operated, supported by a simple, yet, powerful command set. -
Page 5: Specifications
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance Specifications 16 Relays Contact current............. 1AMP @24 VDC 0 . 5 A M P @ 1 2 0 V A C Contact method............... SPST (Form A) Digital Inputs Voltage Range.............. -
Page 6: System Wiring
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance System Wiring Host PC Female Male Female Male N e x t D e v i c e Female ...255 Specifications subject to change without notice. www.intelligent-appliance.com... -
Page 7: Pin Assignment
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance Pin Assignment J1 - INPUT COM (DB9, Female) PIN # FUNCTION J2 - OUTPUT COM (DB9, Male) PIN # FUNCTION R S - 2 3 2 C I n t e r f a c e... - Page 8 16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance Digital Input The IA-3126 Relays controller includes 16 Wide-Range Digital Inputs that might be used as Dry Contact Inputs. Two Jumpers, JP2and JP3, each controls input voltage range of correspondenly inputs 1-8 and 9-16 should be set to one of the two options: +5VDC or Source voltage which connects to TB9.
-
Page 9: Software Instolation
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance Software Installation IA-3000 Utility Install the IA-3000 Utility in your computer by clicking on the ‘Start’ icon in the ‘IA-Utility’ directory, on the IA-3000 CD. Handling IA-3000 Utility Start the IA-3000 Utility by pressing ‘Start’ on the computer’s main screen, select ‘All Programs’, and finally ‘IA-3000’. -
Page 10: Command Set
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance Command Set The following table is a quick reference table for the IA-3126 command set. A host computer / PLC may control the IA-3126 by simply sending ASCII commands through a standard COM port Each command includes a delimiter character, modules address, command character, data if any, and a carriage return character. -
Page 11: Get Device Name
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance ?aa0(cr) Function Get Device Name Description Request the Device model name. Can be used to identify the connected module type at the specified address. Syntax ?aa0(cr) Delimiter character Hexadecimal address of the device... -
Page 12: Get Device Firmware Version
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance ?aa1(cr) Function Get Device Firmware Version Description Request the Device version. Syntax ?aa1(cr) Delimiter character Hexadecimal address of the device Get device Version command (cr) Carriage Return - End of command... -
Page 13: Get I/O Status
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance ?aa2 (cr) Function Get I/O Status Read I/O present status. Description ?aa2(cr) Syntax Delimiter character Hexadecimal address of the device Read I/O status (cr) Carriage Return - End of command... -
Page 14: Get Jp & Led Status
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance ?aaS(cr) Get Jumper & LED Status Function This command reads the stauts of JP1 and the LED. Description ?aaS(cr) Syntax Delimiter character Hexadecimal address of the device Read Jumper & LED Status... -
Page 15: Get Device Mode
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance ?aa5(cr) Function Get Device Mode Description This command reads the module operation mode Syntax ?aa5(cr) Delimiter character Hexadecimal address of the device System Mode command (cr) Carriage Return - End of command... -
Page 16: Get Device Id
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance ?aaID(cr) Function Get Device ID Description This command reads the Device ID Syntax ?aaID(cr) Delimiter character Hexadecimal address of the device Command for read ID (cr) Carriage Return - End of command... -
Page 17: Set Relays Status
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance !aa2DDDD(cr) Function Set Relays Status This command define’s moudule’s output state. Description !aa2DDDD (cr) Delimiter character Syntax Hexadecimal address of the device System control command Relay output activation command data for each nibble in hex format. -
Page 18: Activate Relay N
IA-3126-2 16 Relays 16-ch Wide-Range inputs IA Daisy-chain Series !aa3DD(cr) Function Activate relay N Description This command activate a single relay. Syntax !aa3DD(cr) Delimiter character Hexadecimal address of the module Single relay activation command N Relay ID in hex format... -
Page 19: Deactivate Relay N
IA-3126-2 16 Relays 16-ch Wide-Range inputs IA Daisy-chain Series !aa4DD(cr) Function De activate relay N Description This command De activate a single relay. Syntax !aa4DD(cr) Delimiter character Hexadecimal address of the module De activate relay N command Relay ID hex format... -
Page 20: Set Device Mode
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance !aa5DD(cr) Function Set Device Mode Description This command sets the power-up mode and enables/disables error messages Syntax !aa5DD(cr) Delimiter character Hexadecimal address of the device System Mode command Mode (00-FF) -
Page 21: Set Baud Rate
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance !aa6BB(cr) Function Set Baud Rate Description For compatibility with existing devices the IA-3126 can be set to other standard baud rates Syntax !aa6BB(cr) Delimiter character Hexadecimal address of the device... -
Page 22: Set Module's Address
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance !aa7AA(cr) Function Set Module’s Address Description Each device must have a unique network address. This command defines a module’s address. Factory default is 00Hex. Syntax !aa7AA(cr) Delimiter character Hexadecimal address of the device... -
Page 23: Set Initiate State
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance !aaEDDDD(cr) Function Set intiate state Description This command defines relays state at POWER-UP. Syntax !aaEDDDD(cr) Delimiter character Hexadecimal address of the device System control command Relay output activation command data for each nibble in hey format. -
Page 24: Set Led Status
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance !aaS0D(cr) Function Set LED Status Description This command turnes ON or turnes OFF the LED Syntax !aaSDD(cr) Delimiter character Hexadecimal address of the device Set LED Status LED Status:... -
Page 25: Set Initiate State At All Modules
16 Relays IA-3126-2 16-ch Wide-Range inputs IA Daisy-chain Series Intelligent Appliance ^^E(cr) Function Force Initiate State At All Modules Description This command forces all modules of this net into their pre defined initiate state. Syntax ^^E(cr) Delimiter character Force initiate state command.
