Intelligent Appliance IA-3121-E User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
IA-3121-E
32-ch Solid-State Relay (SSR) Board,
Ethernet IP Controlled
IA Series-3000 Daisy-Chain
Version 0814
www.intelligent-appliance.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the IA-3121-E and is the answer not in the manual?

Questions and answers

Related Manuals for Intelligent Appliance IA-3121-E

Summary of Contents for Intelligent Appliance IA-3121-E

  • Page 1 User Manual IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain Version 0814 www.intelligent-appliance.com...
  • Page 2 Ethernet IP Controlled IA Series-3000 Daisy-Chain Copyright Copyright © 1985-2014 Intelligent Appliance Ltd. All rights reserved. The information in this user manual is subject to change without notice. Microsoft, Windows and Hyper-Terminal are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
  • Page 3 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain INTRODUCTION ..............................4 ..................................4 EATURES ..............................4 RDERING NFORMATION ................................5 PECIFICATIONS INSTALLATION ............................... 6 ................................6 YSTEM IRING Pin Assignment ..............................7 User Defined Jumpers & Led ..........................7 COMMAND SET..............................
  • Page 4 The main advantage of Solid-State Relays is incomparable Long Operation Life, Fast Respond, Silent Operation and best fitting Inductive Loads. The IA-3121-E may be referred to as a High Power 32-ch Digital Output Module, with an Open- Drain Output Stage and an output current capability of up to 1Amp on each channel.

  • Page 5: Warning & Safety

    Weight 220gr Warning & Safety Do not operate the Intelligent Appliance products are NOT authorized for use as components in life device in a manner not support devices or systems. specified in the Do not operate the device in a manner not specified in the documentation. Misuse of documentation.
  • Page 6 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain Installation System Wiring Host PC RJ45 Cable RJ45 Cable Female Male Chaining Device IA-3XXX Female …255 www.intelligent-appliance.com Specifications are subject to change without notice...

  • Page 7: Pin Function

    IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain Pin Assignment J1 – Main Port (LAN) J2 - Expansion Port (RS-232, DB9 Male) Pin Function TB1, 2, 4, 5 – SSR #1 to SSR #32 TB3 – Power supply input terminal User Defined Jumpers &...
  • Page 8 IA Series-3000 Daisy-Chain Command Set The following table is a quick reference table for the IA-3121-E , A host computer / PLC may control the IA-3121-E by simply sending ASCII commands though a standard COM port. Each command is structured from a delimiter character, modules address, command character, data if any carriage returns character.
  • Page 9 Command: ?010<CR> Response: _3121<CR> Request the device at address 01Hex to send its model name. The response indicates that the command was successful and that the device at this address is IA-3121-E www.intelligent-appliance.com Specifications are subject to change without notice...
  • Page 10 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain ?aa1 – Get device firmware version Description Request the Device version Syntax ?aa1<CR> Delimiter character Hexadecimal address of the device Get device Version command <CR> Carriage Return - End of command Response _nnnn<CR>...
  • Page 11 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aa2dddddddd – Set relay status Description This command defines module’s relay state. Syntax !aa2dddddddd <CR> Delimiter character Hexadecimal address of the device System control command Relay output activation command data for each nibble in hex format <CR>...
  • Page 12 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain www.intelligent-appliance.com Specifications are subject to change without notice...
  • Page 13 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aa3dd – Activate relay N Description This command activates a single relay. Syntax !aa3dd <CR> Delimiter character Hexadecimal address of the device Single relay activation command N Relay ID in hex format <CR>...
  • Page 14 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain www.intelligent-appliance.com Specifications are subject to change without notice...
  • Page 15 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aa4dd – De activate relay N Description This command De activates a single relay. Syntax !aa4dd <CR> Delimiter character Hexadecimal address of the device De activate relay N command Relay ID hex format <CR>...
  • Page 16 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain www.intelligent-appliance.com Specifications are subject to change without notice...
  • Page 17 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aa5dd – Set device mode Description This command sets the power-up mode and enables/disables error messages Syntax !aa5dd <CR> Delimiter character Hexadecimal address of the device System Mode command...
  • Page 18 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aa6dd – Set baud rate Description For compatibility with existing devices the IA-4131-U2i-P can be set to other standard baud rates Syntax !aa6dd <CR> Delimiter character Hexadecimal address of the device...
  • Page 19 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aa7dd – Set module’s address Description Each device must have a unique network address. This command defines a module’s address. Syntax !aa7dd <CR> Delimiter character Hexadecimal address of the device...
  • Page 20 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aaBndd – Set Relays Status at Level Description This command sets the status of 8 relays at a time. Syntax !aaBndd <CR> Delimiter character Hexadecimal address of the device Change Byte Level command #Byte to be set.
  • Page 21 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain www.intelligent-appliance.com Specifications are subject to change without notice...
  • Page 22 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aaEdddddddd – Set initial state Description This command defines relays state at POWER-UP Syntax !aaEdddddddd <CR> Delimiter character Hexadecimal address of the device System control command Relay output activation command data for each nibble in hex format <CR>...
  • Page 23 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain !aaMdddddddd – Set Temporary Memory State Description This command defines the temporary memory state Syntax !aaMdddddddd <CR> Delimiter character Hexadecimal address of the device System control command Relay output activation command data for each nibble in hex format <CR>...
  • Page 24 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain ^^E – Force initial state at all modules Description This command forces all modules of this net into their pre-defined initiate state. Syntax ^^E<CR> Delimiter character Hexadecimal address of the device <CR>...
  • Page 25 IA-3121-E 32-ch Solid-State Relay (SSR) Board, Ethernet IP Controlled IA Series-3000 Daisy-Chain ^^M – Activate Relays per Memory Status Description This command forces Activate Relays per Memory Status. Syntax ^^M<CR> Delimiter character Activate Relays per Memory Status <CR> Carriage Return - End of command Response Relay state is set to memory state, no feedback message is returned.
