Summary of Contents for Mooltipass Mini BLE
- Page 1 Mooltipass Mini BLE User Manual Mooltipass Mini BLE User Manual – 2021/08/25...
-
Page 2: Table Of Contents
Enabling Advanced Mode / Enabling Simple Mode ................. 12 Changing the Card PIN ........................12 Cloning your Card ........................... 13 Deleting Your User Data from the Mooltipass ................. 14 Settings Menu (Advanced Mode Enabled) ................... 15 Keyboard Layout Change ........................ 15 Login Notification / Prompt ...................... - Page 3 Synchronization Tab ........................... 27 Settings Tab ............................28 Advanced Tab............................. 29 About Tab ............................30 Importing Existing Profiles Into New Mooltipass Devices............... 30 Native Integration without Browsers ..................... 30 Device Operation with Mobile Phones ....................31 Currently Supported Mode of Operation ..................... 31 Setting the right keyboard layout on Android devices ................
-
Page 4: Mooltipass Mini Ble Device
B) Important Concepts When using the Mooltipass, it is useful to keep the following points in mind in order to use all features that the Mooltipass Mini BLE offers: 1) Each user is identified to the Mooltipass by a personal card or one of its clones... - Page 5 Mooltipass user. Simply insert one of the cards that came with the device into the Mooltipass Mini BLE. The Mooltipass Mini BLE will prompt you to create a new user. Click the wheel to accept the request. Scrolling to the cross icon and clicking, or holding the wheel button (a “long click”) will deny the...
-
Page 6: D) Bluetooth Operation
Your device will generate and display a pairing PIN. When the device has generated the PIN, the Mooltipass Mini BLE will prompt you to enter it. Enter the PIN and the Mooltipass Mini BLE will connect to your device. -
Page 7: B) Deleting Pairings
Bluetooth just turns it off, it does not delete the pairings. d) Switching Between Bluetooth Devices If your Mooltipass Mini BLE is paired with several devices, you can use the “Disconnect Device” menu item to temporarily disconnect the Mini BLE from the currently connected device, allowing another Bluetooth device to connect to it. -
Page 8: E) Credentials Storage And Recall
Mooltipass supports all three methods. For username and password login, your Mooltipass device will behave in one of two ways depending on how it is configured. (See Enabling Advanced Mode / Enabling Simple Mode and Login Notification / Prompt). -
Page 9: C) Fido2 / Webauthn Credentials
FIDO2 / WebAuthn Credentials The Mooltipass Mini BLE natively supports FIDO2 / WebAuthn based credentials. The Mooltipass Mini BLE interacts with them like any other kind of credential. You can test and read more about WebAuthn technology here. d) Time-Based One Time Passwords (TOTP) Time-Based One Time Passwords can be setup using the Moolticute companion app. -
Page 10: E) Manual Login
If more than one credential set is stored for a given website, you will be prompted to select which login to use. If the Mooltipass Mini BLE is connected to different devices, one over Bluetooth and the other over USB, you’ll be prompted to select the output interface. -
Page 11: F) Manual Login - Favorites Menu
And then approve or deny the password entry requests. If you deny both username and password prompts, the Mooltipass Mini BLE will ask if you’d like to display your credential on its screen. Mooltipass Mini BLE User Manual – 2021/08/25... -
Page 12: G) Operations Menu
G) Operations Menu The Mooltipass Mini BLE has an ‘Operations’ menu that provides access to some important features. From the main menu, select the ‘Operations’ item. You will be presented with the available options, which are outlined below. a) Enabling Advanced Mode / Enabling Simple Mode You can switch between the advanced and simple mode using this menu item. -
Page 13: C) Cloning Your Card
Confirm the PIN for the new card. Remove your regular card. Insert a new (empty) smart card. The Mini BLE then initializes it with the contents (encryption key) of your regular card, and the new PIN you just selected. -
Page 14: D) Deleting Your User Data From The Mooltipass
Please note that this operation deletes all the credentials stored for this user on this Mooltipass Mini BLE. It doesn't delete credentials stored for this user on other Mooltipass devices nor credentials stored on this Mini BLE for other users/cards. -
Page 15: H) Settings Menu (Advanced Mode Enabled)
“typing.” b) Login Notification / Prompt This menu item allows you to select whether the Mooltipass Mini BLE should notify, or prompt you whenever you login to a website c) Knock Detection When “login prompt” is enabled, this menu item allows you to enable the knock detection feature: when you’re prompted to login into a website,... -
Page 16: F) Language Change
M) Device Emergency Shutdown In the unlikely case where your device becomes unresponsive, you can force-shutdown your Mooltipass Mini BLE by unplugging it from USB and keeping the wheel pressed for 20 seconds. You may then plug the USB cable again. -
Page 17: Mooltipass Browser Extension
In Chrome, Firefox or Opera, the Mooltipass icon is located next to your address bar. Clicking on it displays a menu. B) Device Status The device status is displayed in the extension menu’s bottom right corner. Mooltipass Mini BLE User Manual – 2021/08/25... -
Page 18: C) Password Generator And Credential Storage
Mini BLE. In the rare cases where the extension doesn’t pick up credential fields, simply right click on a field to bring up a context menu to manually trigger credentials recall. Mooltipass Mini BLE User Manual – 2021/08/25... -
Page 19: E) Selecting Custom Credential Fields
In the rare case the credential fields aren’t picked up, you can tell the app about them by clicking this item in the extension menu. Follow the on-screen instructions to select the username field then the password field, and confirm. Mooltipass Mini BLE User Manual – 2021/08/25... -
Page 20: F) Extension Settings
If you find a website that does not work, we'd like to know about it. To report an incompatibility, click on this link in the extension menu. Mooltipass Mini BLE User Manual – 2021/08/25... -
Page 21: Moolticute Application
Moolticute Application A) General Information Moolticute is the official app for the Mooltipass. It works as an intermediary between your Mini BLE and the browser extension. This allows a simpler, more intuitive use of your Mooltipass and gives you access to more functionality when you need it. For Moolticute and Mooltipass extension installation instructions, please visit http://www.themooltipass.com/setup. -
Page 22: A) Keyboard Output
Keyboard Output ▪ For the Mooltipass to operate properly, it is important that you use the Device Settings tab to select the keyboard layout you are using. ▪ If characters are missing when using manual credential recall, the Mooltipass may be typing too quickly for your computer. -
Page 23: D) Advanced Settings
Knock Detection), knocking twice approves a credentials sending request ▪ Select for how many seconds information should be displayed on the mini BLE screen ▪ Display a screen saver when the device is going to sleep when connected through USB ▪... -
Page 24: E) Advanced Settings - Lock Unlock Feature
Simply use the drop-down list to specify whether a login and/or password should be sent after unlocking your smartcard. The Mooltipass Mini BLE will then the credential for the ‘_unlock_’ service in your database. For help setting up the ‘_unlock_’ service, please refer to Credentials Tab –... -
Page 25: D) Credentials Tab
You can let the Mooltipass Mini BLE generate and store a random password locally by not filling the ‘password’ field, pressing your keyboard ‘Alt’ key, and then clicking the save button. - Page 26 Single clicking on a credential line (2) shows its details. To display the password, click on the eye icon (3) and use the wheel on the Mooltipass Mini to confirm the request. You can edit the displayed credential. To save changes: click on the 'Confirm changes' button. To cancel the credential modification: click and hold the ‘Discard changes’...
-
Page 27: E) Files Tab
Mooltipass device. If the file’s name matches a file already stored in the Mooltipass, the device will ask you if you want to update it. If you confirm the request, the file already stored will be replaced by the one you specified. -
Page 28: G) Settings Tab
▪ enable integration with the ‘have I been pwned’ service. AThis service allows you to be sure your credentials haven’t been compromised ▪ enable the full developer’s log (when the Mooltipass team instructs you to do so) ▪ change the default password length for the password generator... -
Page 29: H) Advanced Tab
If you notice that your Mini BLE has poor battery life (less than 3 days), we invite you to use the “Start NiMH Reconditioning” button that will trigger a 5 hours long process to perform a battery maintenance operation. -
Page 30: I) About Tab
Chrome, Firefox and Opera. As this project is mostly built by volunteer contributors, you are welcome to contact us at #mooltipass on freenode.net if you are interested in giving us a hand. In the meantime, you can use manual login as explained in the... -
Page 31: Device Operation With Mobile Phones
B) Setting the right keyboard layout on Android devices When connected over Bluetooth to your mobile phone, the Mooltipass Mini BLE will be detected as a physical keyboard and Android will therefore assign a layout to it (by default, English US). To change this, follow this procedure: Go to: Settings ->... -
Page 32: Regulatory Mentions
A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas Mooltipass Mini BLE User Manual – 2021/08/25...
